995 / 1410
995
Prices in EURO - VAT not included
995
MULTIMETERS
11
4480GB
Electronic digital/analogue model, multifunctions, for electrotechnicians.
Switch for selecting functions and measurements, safety input jack.
Automatic polarity. Reading on display and bar scale.
Battery charge indicator. Automatic switch off. Back illuminated.
Voltage/continuous current: capacity 400 mV to 1000 V /400 µA to 10 A.
Voltage/alternate current: capacity 400 V to 750 V / 400 µA to 10 A.
Resistance: capacity 400 ohm to 40 M ohm.
Frequency: capacity 10 kHz to 200 kHz.
Relative measurements. Data inserting in memory.
Power: included 3 alkaline 1,5 V battery AAA type (Art. 3600 C).
With 2 pointers.
4480GB
Each 137,00
vuoto
MULTIMETERS
4480GD
new
Multifunctional digital electronic type, for professional electricians.
Switch for electing functions and actions, WITH SAFETY SYSTEM ON INPUT SOCKETS.
MEASUREMENT OF TEMPERATURE through supplied probe.
Automatic polarity. Reading on large backlit display.
With diode test and continuity test.
Voltage / DC: flow rate 200 mV to 600 V / 2 mA to 10 A
Voltage / AC: 2 V to reach 600 V / 2 mA to 10 a
Resistance: capacity 200 ohm to 20 Mohm.
Frequency range 0 kHz to 20 kHz.
Temperature measurement from -20 ° C to + 1000 ° C.
Operated by 1 9 V alkaline battery (Art. 3600 M), supplied.
With 2 pointers and thermocouple probe.
4480GD
Each 112,00
vuoto
Adapter to be used with "K" connection thermocouple probes, Art. SCU 4476 GH to 4476 GS with
multimeter Art. 4480 GD.
O4480GD
Each 9,94
vuoto
MULTIMETERS
4480GE
Electronic digital/analogue model, multifunctions, for electrotechnicians.
Switch for selecting functions and measurements. TEMPERATURE MEASUREMENT by K
probes, Art. 4476 GH, supplied. (For other probes see Art. 4476 GL to 4476 GS).
Automatic polarity. Reading on display and bar scale.
Voltage/continuous current: capacity 50 mV to 1000 V / 500 µA to 20 A.
Voltage/alternate current: capacity 50 mV to 1000 V / 500 µA to 10 A.
Resistance: capacity 50 ohm to 50 M ohm.
Frequency: capacity 5 kHz to 125 kHz.
Relative measurements. Data inserting in memory.
Measurable temperatures from -50 °C to +1000 °C.
Power: with included one alkaline 9V battery (Art. 3600 M), supplied.
Interface for PC: RS 232.
With 2 pointers and thermocouple probe Art. 4476 GH.
4480GE
Each 320,00
vuoto
MULTIMETERS
LAN-TESTERS AND MULTIMETERS
4480GP
Prod. SCU
Electronic digital model for LAN network and multimeter function test con portata automatica.
Switch for selecting functions and measurements Automatic polarity. Reading on display of
multimeter functions. LED displays the real pin configuration of 10BASE-T and 10BASE-2 Thin
Ethernet, FJ45/RJ11 modular, 58A, tia-568a/568b and Token Ring cables (ring network).
Provides easy to read continuity and fault status display. Checks for continuity, open wire, ground
wire, shorted pair and crossed pair faults. Auto or manual scanning for LAN testing.
Test diode.
Discharged battery indication.
Voltage/continuous current: capacity 200 mV to 600 V/ 200,0 µA to 200,0 mA
Voltage/alternate current 50-60 Hz: capacity 2.000 V to 20.00 V - 200.0 V to 600 V/200.0 µA to
200.0 mA
Resistance: capacity 200.0 ohm to 20.00 Mohm
Power supply: 1 9V alkaline battery (Art. 3600 M) and 2 alkaline batteries 1.5 V "AAA" (Art. 3600
C), supplied.
With pointer couple, LAN test cable, 2 x female cables BNC-RS 45 and double male adapter BNC.
4480GP
Each 153,00
vuoto
LAN-TESTERSANDMULTIMETERS
