1001 / 1410
1001
Prices in EURO - VAT not included
1001
ELECTRONIC TESTERS
11
ELECTRONIC TESTERS
4482E
Prod. SCU
Bipolar system with LED which allows the user to check the presence of continuous and alternate
current 6 - 380 V as well as polarity.
4482E
Each 19,40
vuoto
ELECTRONICTESTERS
4482GA
High insulation model, manufactured in compliance with VDE 0680/5 standards.
Bipolar system with LED, which allows the user to check the presence of continuous and alternate
current of 12 - 690 V.
4482GA
Each 29,40
vuoto
ELECTRONICTESTERS
4482GE
IP65
High insulation model according to IEC/EN 61243-3 (DIN VDE 0682-401), professional, bipolar.
Using the LEDs the following functions can be performed:
- determine the value of DC and AC voltages from 6-1400 V / 6-1000 V
- polarity test, test for the direction of the rotating field (max 400 V)
- continuity check of circuits with a resistance between 0 and 50 K ohms, with optical/acoustic
signal
- diodes and safety switch test as a result of failures
- phase test towards ground.
Powered by: 2 1.5 V alkaline batteries, AAA type (Art. 3600 C), supplied.
4482GE
Each 120,00
vuoto
ELECTRONICTESTERS
4482GH
High insulation model, manufactured in compliance with VDE 0682-401 standards.
By means of a LED, it is possible to:
- check the presence of direct and alternate current of 6 - 400 V.
- determine the voltage value
- check polarity
- incoming resistance 0 to 250 kO
4482GH
Each 65,80
vuoto
ELECTRONICTESTERS
4482GL
IP65
ELECTRONIC DIGITAL model, high insulation in compliance with VDE 0680/5 standards. Ideal
for laboraories, workshops and specialised technicians.
Universal instrument, completely safe, for continuous and alternate currents 5 - 690 V.
Determines the voltage value. Automatic switch-off.
Possible functions:
- to measure voltages
- to test current flow by means of 2 batteries of 1.5 V type AAA (Art. 3600 C), supplied.
- to test phase towards ground
- to test polarity
- to test semi-conductors
- to test conductance with resistance range 0-500 K ohm.
Input voltage
Volt
5 ÷ 690
Frequency range
Hz
0 ÷ 100
4482GL
Each 215,00
vuoto
ELECTRONICTESTERS
4482GP
IP65
DIGITAL ELECTRONIC type with high insulation according to IEC / EN 61243-3 (DIN VDE 0682-
401), professional, bipolar. Ideal for laboratories, workshops, technicians and installers.
With LCD-display with backlight and automatic shutdown can perform the following functions:
- determining the value of DC and AC voltages from 4-1400 V / 3 -1000 V
- test polarity, the direction of the rotating field (max 400 V)
- resistance measurement from 1-1999 ohms
- rate measurement from 10-1000 Hz
- control continuity of circuits with resistance between 0 and 50 K ohms, with acoustic signal
- testing of safety switches as a result of failure of the current test phase to earth.
- Data-Hold
Power: 2 alkaline batteries 1.5V AAA (Art. 3600 C), supplied.
4482GP
Each 206,00
vuoto
ELECTRONICTESTERS
