Prices in EURO - VAT not included
937
PRECISION MAGNETIC V BLOCKS
11
4331GM
4/1000
Prod. SCU
Magnetic type. Switching on and off through switch.
In hardened steel, ground and lapped. Accuracy: 0.004mm.
Particularly suitable to be used on machine tools.
In wooden case.
Size
80
100
Dimensions
mm 80x67x96 100x70x96
Ø for cylindrical bodies
mm 6-66
6-70
Prism side magnet force kN 400
400
Flat side magnet force
kN 900
1200
4331GM
Each 642,00
822,00
For single use
vuoto
PRECISIONMAGNETICVBLOCKS
4331P
1/100
2/100
Magnetic type. Switching on and off through switch.
In hardened steel, ground and finely worked. Accuracy: parallellism 0.01mm, orthogonality
0.02mm, angular 0.02mm.
Particularly suitable to be used on machine tools.
Size
85
130
Dimensions
mm 85x70x85 130x70x85
Ø for cylindrical bodies
mm 50
50
4331P
Each 573,00
690,00
For single use
vuoto
PRECISIONMAGNETICVBLOCKS
4331T
1/100
Orig. Mib
Magnetic type. Switching on and off via switch.
In hardened steel, ground and finely polished.
Particularly suitable for use on machine tools.
Dimensions 95x70x100mm. For cylindrical bodies Ø 6-66mm. Flat side magnet strength 1000kN.
4331T
Each 173,00
For single use
vuoto
PRECISIONMAGNETICVBLOCKS
PRECISION V BLOCKS
4332
2/100
Prod. SCU
Right angle type, in steel.
Ground surfaces.
Accuracy: 0.02mm. Sold in two’s only.
Size
100
150
200
Dimensions
mm 100x45 150X55 200x70
4332
Per pair 97,90 162,00 219,00
vuoto
PRECISIONVBLOCKS
SURFACE PLATES
4335
2/100
Prod. SCU
Heavy finish in special cast iron, indeformable.
Ground surface.
Accuracy according to DIN 876, II Degree
Dimensions
mm
300x200 400x300 500x300 500x400 600x500 800x500
Tolerance ±
mm 0,013 0,014 0,015 0,015 0,016 0,018
Weight
Kg
10
20
28
35
55
80
4335
Each 291,00 465,00 551,00 688,00 989,00 1.420,00
vuoto
SURFACEPLATES
4336
1/100
Product description as Art. 4335
Accuracy according to DIN 876, Grade I
Dimensions
mm
300x200 400x300 500x300 500x400 600x500 800x500
Tolerance ±
mm 0
,0065 0,007 0,0075
0
,0075 0,008 0,009
Weight
Kg
10
20
28
35
55
80
4336
Each 326,00 525,00 666,00 782,00 1.170,00 1.620,00
vuoto
SURFACEPLATES
