936 / 1410
936
Prices in EURO - VAT not included
936
HAND SCRIBERS WITH PUNCH
11
4325GA
Orig. MIB - Art. 04055019
Spare tip in hard metal, double, turneable for Art. 4325 G.
4325GA
Each 5,48
vuoto
HANDSCRIBERSWITHPUNCH
STEEL MARKING GAUGES
4328G
Prod. SCU
In steel. Marker with millimeter round rod.
Slider support flange. Reading: 1/10 millimeter.
Carbide scriber Ø mm 6.
Capacity
mm
200
300
500
4328G
Each 60,30
75,40
94,20
vuoto
Spare scriber in hard metal, for Art. 4328 G 200-300-500.
O4328GA
Each 14,40
vuoto
STEELMARKINGGAUGES
4328GE
Flat type. Made of hardened steel, chrome plated, matt. Millimetre scale.
Capacity
mm
200
250
300
4328GE
Each 23,10 24,10 25,10
For marker calipers see Art. 3749 B.
vuoto
STEELMARKINGGAUGES
STEEL MARKING GAUGES WITH SQUARES
4328GL
INOX
Prod. SCU
Combined with team model for tracking operations, measurements of angles. Central body with
stainless steel Protractor, graduated with a circular scale is divided into 4 parts from 0° to 90°.
With flat Guide, Matt-finish chromium graduated, with capacity from 0 to 300 mm.
4328GL
Each 63,20
vuoto
STEELMARKINGGAUGESWITHSQUARES
QUADRUPLE V BLOCKS
4330
2/100
Prod. SCU
Cross-type, in steel. With ground surfaces.
Accuracy: 0.02mm. Sold in two’s only.
Size
60
75
100
120
150
Dimensions
mm 60x60 75X75 100X80 120x90 150x100
4330
Per pair 121,00 151,00 196,00 253,00 339,00
vuoto
QUADRUPLEVBLOCKS
PRECISION V BLOCKS
4331G
4/1000
Prod. SCU
Cross-type, with clamp for cylinders. In hardened steel, ground and lapped. Two 90° angles.
Accuracy: 0.004mm.
Sold in two’s only.
Size
50
75
100
Dimensions
mm 50x40x40 75x55x55 100x75x75
Ø for cylindrical bodies
mm 5-30
5-50
7-70
4331G
Per pair 194,00
254,00
345,00
vuoto
Wooden case for Art. 4331G.
Size
50
75
100
O4331G
Each 27,70
35,50
55,40
vuoto
PRECISIONVBLOCKS
PRECISION MAGNETIC V BLOCKS
4331GE
5/1000
Orig. Mib
Magnetic type. Switching on and off via switch.
In hardened steel, ground and lapped in PAIRS. Accuracy: 0.005mm.
Particularly suitable for use on machine tools.
Sold in pairs only.
Size
80
100
Dimensions
mm 80x67x96 100x70x96
Ø for cylindrical bodies
mm 6-66
6-72
Prism side magnet force
kN
400
400
Flat side magnet force
kN 1000
1200
4331GE
Per pair 1.110,00 1.570,00
vuoto
PRECISIONMAGNETICVBLOCKS
