930 / 1410
930
Prices in EURO - VAT not included
930
PRECISION CENTERING SQUARES
11
PRECISION CENTERING SQUARES
4267GE
875/I
Prod. SCU
In steel. Finely ground, chrome plated. Graduations in millimitersm. Angle bisector accuracy
according to DIN 875/I. Suitable for 45° and 90° angles, for locating round centres and for tracing.
Dimensions
mm
100x70 150x130 200x150
For shafts up to Ø
mm 90
190
220
4267GE
Each 43,60 52,60 64,20
vuoto
PRECISIONCENTERINGSQUARES
FLANGE SQUARES
4267GF
Prod. SCU
In steel, polished surface.
Dimensions
mm
300x300 500x500
Section
mm 30x5 30x5
4267GF
Each 23,10 34,80
vuoto
FLANGESQUARES
4267L
Elbow type, in steel, ground.
Arc’s opening mm 60. Arc’s depth mm 160.
Dimensions
mm
300
500
Section
mm 30x6 30x6
4267L
Each 65,60 67,10
vuoto
FLANGESQUARES
ADJUSTABLE SQUARES
4268G
Prod. SCU
In steel, finely polished.
With lock screw.
Overall length
mm
200
250
300
4268G
Each 14,20 18,30 19,90
vuoto
ADJUSTABLESQUARES
COMBINATION SQUARES
4270GA
Prod. SCU
Standard type with graduated blade, one side in mm, the other side in inches.
Sliding base for 45° - 90° angles and vial.
Rod length
mm 300
4270GA
Each 11,70
vuoto
COMBINATIONSQUARES
4270GE
Orig. MIB - Art. 03047011
Model complete with graduated blade, one side in mm, the other side in inches.
45° to 90° multidegree square, level, scriber, goniometer, surface gauge.
Rod length
mm 300
4270GE
Each 78,30
vuoto
COMBINATIONSQUARES
4275G
INOX
Prod. SCU
Combination model with goniometer, adjusting square , 3 vials and scriber tracciare.
Graduated blade in stainless steel.
Rod length
mm 180
4275G
Each 11,60
vuoto
COMBINATIONSQUARES
