RATCHET PUNCHING PLIERS
2
91
Prices in EURO - VAT not included
RATCHET PUNCHING PLIERS
430GA
Orig. Baudat - Art. 80-802. (Mod. LZ 2000)
Special type with ratchet movement for powerful punching action (200KN).
Limited load, die and punch integrated in one single interchangeable support for rapid adjustment.
Special steel head and plastic ergonomic handles with hand protector.
Weight 1,3Kg.
Without die/punch support.
Overall length
mm 280
Max span
mm
50
For sheets with max. thickness mm
2
For round bores by
mm 4 to 13
For rectangular bores by
mm 5x10 to 7x13
430GA
Each 572,00
vuoto
RATCHETPUNCHINGPLIERS
430GB
Orig. Baudat
DIES SUPPORTS COMPLETE WITH ROUND PUNCHES FOR ART. 430 GA
Die support with punch.
Ø
mm
4,2
5
6
7
9
10,5 11
13
430GB
Each 157,00 157,00 157,00 157,00 157,00 157,00 157,00 157,00
vuoto
RATCHETPUNCHINGPLIERS
430GE
DIES SUPPORTS COMPLETE WITH RECTANGULAR PUNCHES FOR ART. 430 GA
Die support with punch.
Dimensions
mm
5x10 5x13 6x13 7x13
430GE
Each 586,00 586,00 586,00 586,00
vuoto
RATCHETPUNCHINGPLIERS
PUNCHING AND SHEET FOLDING PLIERS
431E
Prod. SCU
Body in die-cast aluminium. Hardened forming jaws.
The welding of two metal sheets results in perfectly parallel surfaces. For metal sheets max
thickness 1mm.
FOLDING PLIERS
Pliers type with return spring.
Overall length
mm 220
Jaws width
mm 10
431E
Each 65,20
vuoto
PUNCHINGANDSHEETFOLDINGPLIERS
431G
Prod. SCU - Orig. Tama
Steel body. Hardened forming jaws. Plastic-coated handles.
The welding of two metal sheets results in perfectly parallel surfaces. For metal sheets max
thickness 1mm.
FOLDING PLIERS
Pliers type with double fulcrum and return spring.
Overall length
mm 300
Jaws width
mm 22
431G
Each 77,10
vuoto
PUNCHINGANDSHEETFOLDINGPLIERS
431G 5
Product description as Art. 431G
PUNCHING AND FOLDING PLIERS
Pliers type with return spring.
Revolving head for better positioning while working. With punch Ø 6mm.
Overall length
mm 290
Profiling depth
mm 20
Jaws width
mm 22
Punch max span
mm 7
To punch Ø
mm 4-5-6-7
431G 5
Each 115,00
For spare punches and dies see Art. 432 GT.
