PUNCHING PLIERS
2
90
Prices in EURO - VAT not included
PUNCHING PLIERS
430E
Prod. SCU
Body in die-cast aluminium. For punching metal sheets of any shape with minimum effort
(stainless steel sheets excluded). Interchangable, re-sharpable punch
Overall length 220mm. Max. opening 20mm. Return spring. Pliers complete with 1 set of punch
and die.
For bores Ø
mm
5
6
8
For sheets with max. thickness mm 1,2
1,2
0,8
430E
Each 63,40 63,40 77,50
vuoto
Spare punch and die sets for Art. 430 E
For bores Ø
mm
5
6
8
O430E
Per pair
22,90 22,90 26,50
vuoto
PUNCHINGPLIERS
430G 1
Prod. SCU - Orig. Tama
Body in solid steel C60. For punching metal sheets, plastic, leather, cardboard, etc. with minimum
effort.
With spacer for punching adjustment. Double-fulcrum lever. High-resistance steel punches.
The smallest punching machines. Front head.
With punch Ø 5mm.
Overall length
mm 220
Max span
mm 20
For sheets with max. thickness mm 1
For bores by
mm 2 to 5
430G 1
Each 77,10
For spare punches and dies see Art. 432 G.
vuoto
PUNCHINGPLIERS
430G 2
Product description as Art. 430G 1
Reinforced type. Front head.
With punch Ø 5mm.
Overall length
mm 260
Max span
mm 30
For sheets with max. thickness mm 1.5
For bores by
mm 2 to 5
430G 2
Each 77,10
For spare punches and dies see Art. 432 G.
vuoto
PUNCHINGPLIERS
430G 4
Product description as Art. 430G 1
With return spring, head suitable for punching angular bodies.
With spacer.
With punch Ø 6mm.
Overall length
mm 300
Max span
mm 40
For sheets with max. thickness mm 1.25
For bores by
mm 4 to 6
430G 4
Each 115,00
For spare punches and dies see Art. 432 GM.
vuoto
PUNCHINGPLIERS
430G 5
Product description as Art. 430G 1
Pliers type.
With puncher Ø 8mm.
Overall length
mm 315
Max span
mm 40
For sheets with max. thickness mm 1.75
For bores by
mm 2 to 8
430G 5
Each 115,00
For spare punches and dies see Art. 432 GS.
vuoto
PUNCHINGPLIERS
430G 8
Product description as Art. 430G 1
Pliers type.
Reinforced details.
High-resistance steel punches. Weight 4,5Kg.
With punch Ø 10mm.
Overall length
mm 520
Max span
mm 40
For sheets with max. thickness mm 1.5
For bores by
mm 3 to 10
430G 8
Each 499,00
For spare punches and dies see Art. 432 GV.
vuoto
