896 / 1410
896
Prices in EURO - VAT not included
896
METERS OF COATINGS THICKNESSES
11
METERS OF COATINGS THICKNESSES
3960GP
new
Prod. SCU
Professional, high precision, electronic digital type, with separate interchangeable probes for
measuring the thickness of non-magnetic coatings such as paints, plastics, enamel materials,
chromium, copper, zinc etc. Changing the supplied probe it is also possible to measure non-
ferromagnetic coatings on metal surfaces (such as aluminum, copper, brass). Ideal for
companies, body shops and professionals.
Measuring capacity from 0 to 1000 pm / from 0 to 40 mil. Accuracy ± 2.5 mM ± 3.1% / ± 1.3%.
Minimum measuring field Ø mm 5. Minimum bending radius: convex iron ca. 1.5 mm, non-ferrous
materials mm 3. Minimum thickness of the substrate: iron 0.5 mm, non-ferrous materials 0.3 mm.
Operated by 4 alkaline batteries 1.5V AAA (Art. 3600 C), supplied. Weight 220 g.
With 2 interchangeable probes Fe and NFe.
3960GP
Each 789,00
vuoto
METERSOFCOATINGSTHICKNESSES
ULTRASONIC METERS OF THICKNESS
3960GT
new
Prod. SCU
Professional, high precision, electronic digital type, with separate ultrasonic probe for measuring
the thickness of materials such as steel, aluminum, copper, brass, quartz glass, PVC, zinc, iron,
gray cast iron, polyethylene. Thanks of the possibility to set the resonance frequency it is also
possible to measure all the other materials. Suitable for many applications from industry to
professionals.
Measuring capacity from 1.2 to 200 mm. Accuracy ± 0.5 mm. Resolution 0.1 mm. Minimum
measuring field Ø mm 5.
Operated by 4 alkaline batteries 1.5V AAA (Art. 3600 C), supplied. Weight 220 g.
With 1 ultrasound probe.
3960GT
Each 832,00
vuoto
ULTRASONICMETERSOFTHICKNESS
MEASURING GAUGES FOR CRANKSHAFT
3961GA
3961GB
3961GE
1/100
Prod. SCU - Orig. Helios-Preisser
Measuring gauge suitable to check the distance between the cranks of a shaft and to check the
cylinder measures. Place the measuring gauge between the two elbows and rotate the shaft to
detect possible bushing misalignements.
The gauge is supplied with a special counterweight that allows positioning stability during
measurement. Supplied with reading comparator 1/100, counterweight, extension rods and caps.
In case.
Art......................................
3961GA 3961GB 3961GE
Capacity
mm 45-150
60-300
60-500
Each 978,00
882,00 1.030,00
vuoto
MEASURINGGAUGESFORCRANKSHAFT
TIRE TREAD FEDER GAUGES
3961GT
1/10
Prod. SCU
In brass, 20mm symmetric baseplate. End tipped rod.
Vernier scale 1/10 mm. Particularly suitable for tyre track measurements.
Measuring range 30mm, length 100mm.
3961GT
Each 6,22
vuoto
TIRETREAD FEDERGAUGES
3961GV
1/10
In brass, 40mm symmetric baseplate. End tipped rod.
Vernier scale 1/10 mm. Particularly suitable for tyre track measurements.
Measuring range 50mm, length 105mm.
3961GV
Each 8,62
vuoto
TIRETREAD FEDERGAUGES
3961GVA
new
1/10
Orig. MIB - Art. 01007055
In brass, 50mm symmetric baseplate. End tipped rod.
Vernier scale 1/10 mm. Particularly suitable for tyre track measurements.
Measuring range 50mm, length 100mm.
3961GVA
Each 14,10
vuoto
TIRETREAD FEDERGAUGES
