895 / 1410
895
Prices in EURO - VAT not included
895
THICKNESS MEASURING INSTRUMENTS
11
3956GA
1/100
Professional model, rollers and runners contact surface, width 8.7mm and diameter 8.4mm.
Effective opening 5mm. Bow depth 50mm. Particularly suited to measure the thickness of cables,
wire, bands, etc. Increments in 1/100 mm, sensitive lever and automatic recoil. Wide dial dor easy
reading with two indicators for millimiters, 1/10 millimiters and 1/100 millimiters.
3956GA
Each 474,00
vuoto
THICKNESSMEASURING INSTRUMENTS
3958
1/100
Increments in 1/100 mm, with sensitive lever and automatic recoil.
Particularly suited to measure the thickness of linings and tappets in the automotive sector.
Lower flat basement and contact surface, ball upper contact surface.
Bow depth 50mm, effective opening 10mm.
3958
Each 119,00
vuoto
THICKNESSMEASURING INSTRUMENTS
3959G
1/1000
Professional model, highly precise. Increments in 1/1000 mm.
Particularly suited to measure sheets of very thin thicknessf.
Insulated handle to avoid hand heat influence. Controlled pressure force of approx. 2 Nm. Bow
depth 30mm. Effective opening 1mm (one indicator revolution corresponds to 0.2mm). Flat round
contact surface Ø 6.3mm.
3959G
Each 464,00
vuoto
THICKNESSMEASURING INSTRUMENTS
3960G
1/10 5/100
Particularly suited to measure saw teeth alternation.
4 contact surfaces to directly show on display the position of the alternate tooth. Increments in 1/
10 mm and + 5/100 mm.
Measuring range 2mm.
Taster diameter mm 10.
3960G
Each 116,00
vuoto
THICKNESSMEASURING INSTRUMENTS
DIGITAL THICKNESS MEASURING INSTRUMENTS
3960GL
Prod. SCU
Professional digital type with LCD display with figures of great height for easy reading. 2 external
probes to easily reach the most difficult points. Cable length 1 meter. Body of sturdy plastic,
reinforced. Equipped with plate zeroing and calibration films. Offset-Accur function for a
measurement with higher precision than the standard (1% of the measured value).
Suitable for measuring insulating coatings on magnetic metals (ferrous) and insulating coatings
on non-magnetic metals (non-ferrous) . Built to meet ISO 2178. Power supply: 4 alkaline batteries
1.5 V AA (Art. 3600 E) provided. Minimum radius of surface for coatings for magnetic / non
magnetic materials with convex shape mm 1.5 /3 and concave shape mm 25/50.
Measuring field
µm 0-1000
Standard measuring precision
5%
Offset-Accur measuring precision
1%
Base material minium thickness
mm 0,3
Minimum surface Ø
mm 6
Working temperature
0°C - 50°C
Device dimensions
mm 161x69x32h
Weight
grams
260
3960GL
Each 672,00
vuoto
DIGITALTHICKNESSMEASURING INSTRUMENTS
