838 / 1410
838
Prices in EURO - VAT not included
838
AUTOMATIC DRAIN VALVES
10
AUTOMATIC DRAIN VALVES
3468GP
Orig. Ewo - Art. 441
Automatic condensation drain valve to be installed inside the air filters glass with hole Ø 14mm
and hexagon guide 19mm.
One size for all the EWO filter dimenions. Body in brass and synthetic material Ø 24mm. Min/max
operating pressure: 1/12 bar (Atm).
3468GP
Each 39,40
vuoto
AUTOMATICDRAINVALVES
3468GV
Orig. Ewo - Art. 5370
External automatic drain valves made of metal. One size for all the combinations COMBIBLOC -
VARIOBLOC - EWO TOP. Min/max operating pressure 4/16 bar (Atm). To be screwed on the filter
glass in place of the manual valve.
3468GV
Each 82,30
vuoto
AUTOMATICDRAINVALVES
MINI LUBRICATORS
3469E
Orig. Ewo - Art. 317.10
Mini-lubricators to be connected directly to the compressed air tools. Small. Oil level visible.
Aluminium alloy body and polycarbonate container. Working pressure: approx. 6 bar (Atm).
Working temperature: 0°/50°C. Contents: 5.5 cm
3
oil with viscosity VG 32 (Art. 1730 G).
Inner/outer connection. 1/4 GAS.
3469E
Each 18,10
vuoto
MINILUBRICATORS
3469G
Orig. Ewo
Mini-lubricators to be connected directly on pen-shaped or handled tools which work at rhythmical
impulses. Caracterised by small dimensions and light weight. Oil lever is visible. Adjustable oil
flow.
Made of aluminium, with polycarbonate glass. Nebulising and regulating components made of
brass. Operating pressure: 6bar (Atm) approx. Operating temperature range: 0°/50 °C. Content:
12 cm
3
of oil with viscosity VG 32 (Art. 1730 G). Regulation: 0.4 cm
3
per 100 pulses approx.
Drive
inch
1/4
3/8
Supplier code ....................
317.12 317.14
3469G
Each 53,40 53,40
vuoto
MINILUBRICATORS
FILTERS FOR COMPRESSED AIR UP TO 40 BAR
3470GT
Orig. Ewo - Art. 445-454
Modular type for very high pressures up to 40 bar. Apt for filtering, upstream, the air of circuits.
Sintered brass filter, aluminium body, brass glass. Manual drain valve. Supplied with test
certification.
Drive
inch
3/8
1/2
3/4
1
1.1/2
2
3470GT
Each 227,00 227,00 263,00 263,00 1.030,00 1.030,00
Available on request purifier filters for compressed air up to 60 BAR fitting 3/4-1 inches.
vuoto
FILTERSFORCOMPRESSEDAIRUPTO 40BAR
