835 / 1410
835
Prices in EURO - VAT not included
835
VARIOBLOC COMBINATION AIR TREATEMENT UNITS
10
3464GRE
Orig. Ewo - Art. 480
Product description as Art. 3464GR 1
Sets of modular COMPACT joints with gaskets.
Drive
inch
1/4
3/8
1/2
3/4-1
Dimensions (A)
mm 30,4
30,4
41,6
41,6
Dimensions (B)
mm 11
11
16
16
Dimensions (C)
mm 24
24
29
29
Dimensions (D)
mm 40
40
52
52
3464GRE
Each 5,48
9,24 10,80 10,80
vuoto
VARIOBLOCCOMBINATIONAIR TREATEMENTUNITS
3464GRF
Product description as Art. 3464GR 1
Sets of modular COMPACT joints with gaskets and wall bracket.
Drive
inch
1/4
3/8
1/2
3/4-1
Dimensions (A)
mm 75
75
110
110
Dimensions (B)
mm 19
19
16
16
Dimensions (C)
mm 35
35
55
55
Dimensions (D)
mm 90
90
130
130
Dimensions (E)
mm 6,5
6,5
6,5
6,5
Dimensions (F)
mm 12
12
9,5
9,5
3464GRF
Each 10,40 10,40 19,90 19,90
vuoto
VARIOBLOCCOMBINATIONAIR TREATEMENTUNITS
3464GRL
Product description as Art. 3464GR 1
Wall brackets for modular COMPACT joints.
Type
1
2
Drive
inch 1/4-3/8 1/2-3/4-1
Dimensions (A)
mm 75
110
Dimensions (B)
mm 16
16
Dimensions (C)
mm 14
26
Dimensions (D)
mm 90
130
Dimensions (E)
mm 6,5
6,5
Dimensions (F)
mm 9,5
9,5
3464GRL
Each 5,02
9,32
vuoto
VARIOBLOCCOMBINATIONAIR TREATEMENTUNITS
3464GRT
Orig. Ewo - Art. 443
Product description as Art. 3464GR 1
Brackets complete with nuts to mount gearboxes and assemblies to the base of the adjustment
ring.
Type
1
2
Drive
inch 1/4-3/8 1/2-3/4-1
Dimensions (A)
mm 40
55
Dimensions (B)
mm 26,5
35
Dimensions (C)
mm 30
42,5
Dimensions (D)
mm 30
40
Dimensions (E)
mm 5,5
7
Dimensions (F)
mm 16
20
Dimensions (H)
mm 30,5
43
3464GRT
Each 7,36
12,20
vuoto
VARIOBLOCCOMBINATIONAIR TREATEMENTUNITS
3464GRV
Orig. Ewo - Art. 480
Product description as Art. 3464GR 1
Brackets complete with screws to mount gearboxes, filters, lubricators and assemblies.
Type
1
2
Dimensions (A)
mm 50
74
Dimensions (B)
34
50
Dimensions (C)
mm 15
20
Dimensions (D)
mm 71
88
Dimensions (E)
mm 5,5
7
Dimensions (F)
mm 16
19
Dimensions (G)
mm 25
28
3464GRV
Each 14,70
15,60
vuoto
VARIOBLOCCOMBINATIONAIR TREATEMENTUNITS
