Prices in EURO - VAT not included
690
MACHINE VICES
9
2874G
Orig. MIB
Precision model.
Required for milling, grounding and checkingoperations.
Completely made of high resistance steel, hardened and ground on all sides.
Jaw with V-slot for a safer grip.
Jaw extension with threaded screw
Jaws width
mm
50
72
100
Max opening
mm 60
100
127
Jaws height
mm 25
35
45
Overall length
mm 155
210
260
Weight
Kg
2,1
5,6
15
Supplier code ....................
06066050 06066051 06066052
2874G
Each 235,00
298,00
470,00
vuoto
MACHINEVICES
2874GE
Product description as Art. 2874G
Jaw extension rapid adjustment
Jaws width
mm
50
75
100
Max opening
mm 70
100
125
Jaws height
mm 25
35
45
Overall length
mm 140
190
246
Weight
Kg
1,6
3,9
9,5
Supplier code ....................
06066056 06066057 06066058
2874GE
Each 173,00
220,00
360,00
vuoto
MACHINEVICES
2876G
new
Prod. SCU - Röhm
High-precision SELF-CENTERING type for machining workpieces on 5 sides for NC machines.
Compact size, with large clamping jaws for a firm grip of the piece. Made entirely of high hardness
steel, hardened and milled. Interchangeable jaws in steel, hardened and ground.
Concentric locking jaws with manual feed. The device can be connected to a torque wrench for
precise and constant tightening. Maximum force applicable 150. Nm. (Tightening repeatability
0.02 mm).
Jaws width
mm 125
Dimensions B min
mm 23
Dimensions B max
mm 142
Dimensions B1
mm 17-136
Dimensione C
mm 128
Dimensions d
mm 218
Dimensions E
mm 196,5
Dimensione F
mm 180
Dimensione N
mm 156,5
Dimensions U
mm 20
Dimensione X
mm 6
Tightening force
kN 25
Weight
Kg 17,4
2876G
Each 4.330,00
vuoto
MACHINEVICES
PARALLEL COUPLES
2878GT
new
Orig. MIB - Art. 06062033
In special hardened steel, hardness HRC 60. Rectified and lapped, in pairs. Accuracy ± 0.005
mm. Used in the mechanical field for clamping in parallel, as support for clamps, etc.
Parallel total length 160 mm
Series of 9 couples with width x thickness
mm 4x10 - 4x14 - 4x18 - 4x22 - 4x26 - 4x30 - 4x34 - 4x38 - 4x42.
In wooden box.
2878GT
Each 235,00
vuoto
PARALLELCOUPLES
2879
Orig. MIB - Art. 06062032
Product description as Art. 2878GT
Parallels total length 150 mm. The set consists of Nr. 14 couples having the following thickness x
width: 10x14 - 10x16 - 10x18 - 10x20 - 10x22 - 10x24 - 10x26 - 10x28 - 10x30 - 10x32 - 10x35 -
10x40 - 10x45 - 10x50 mm.
Supplied in case.
2879
Each 345,00
