687 / 1410
687
Prices in EURO - VAT not included
687
ACCESSORIES FOR STEEL DROP-FORGED VICES
9
ACCESSORIES FOR STEEL DROP-FORGED VICES
2861GA
Orig. KANCA
All vices Art. 2859 GA are provided with devices specifically designed for following jaws and other
accessories.
Steel collapsible jaws for pipe processing.
Jaws width
mm
125
135
150
175
2861GA
Each 48,60 57,40 61,80 70,60
The jaw width 125 mm is also suitable for the vices Art. 2859 GA L-115.
vuoto
ACCESSORIESFORSTEELDROP-FORGEDVICES
2861GB
Product description as Art. 2861GA
Unbreakable plastic jaws.
Jaws width
mm
115
125
135
150
175
2861GB
Each 43,10 45,20 47,50 49,70 54,10
vuoto
ACCESSORIESFORSTEELDROP-FORGEDVICES
2861GF
Screw terminals for bench fixing of vices Art. 2856 GA / 2859 GA.
For vices
mm
100
115
125
Terminal opening
mm 85
85
85
2861GF
Each 90,40 90,40 90,40
vuoto
ACCESSORIESFORSTEELDROP-FORGEDVICES
LIFT MOBILS
2861GR
Orig. KANCA - Art. LIFT MOBIL
Vice weight compensation type, vertical adjustment and rotation device to conceal the vice under
the bench. Telescopic vertical movement mechanism and 360° horizontal rotation. It allows free
bench for working necessities. For vices Art. 2856 GA and 2859 GA. Without vice.
For vices
mm
100
115
125
Max elevation
mm 270
270
270
Support plate Ø
mm 120
135
145
Weight
Kg
13
14
15
2861GR
Each 642,00 642,00 642,00
vuoto
LIFTMOBILS
AUTOMATIC ELEVATORS
2861GS
Orig. KANCA
Vice weight compensation type, vertical adjustment.
Telescopiv vertical movement, gas thrust control.
360° horizontal rotation. With lock lever.
For vices Art. 2856 GA and 2859 GA. Without vice.
For vices
mm
100
115
125
135
Max elevation
mm 250
250
250
250
Support plate Ø
mm 135
135
160
160
Weight
Kg
8,8
8,8
9,2
9,2
2861GS
Each 375,00 375,00 375,00 375,00
vuoto
AUTOMATICELEVATORS
SHANK VICES
2861GT
Orig. KANCA
Body in semisteel cast iron, induction hardened jaws.
Particularly suitable for carpenters, blacksmiths, etc.
Jaws width
mm
125
150
Opening
mm 130
140
Working depth
mm 100
100
Overall length
mm 1040 1070
Weight
Kg
24
25
2861GT
Each 461,00 534,00
vuoto
SHANKVICES
PIPE WORKING VICES
2863
Prod. SCU
Body in rolled steel.
Milled jaws, hardened.
For pipes up to
inch
2
3
4
6
Weight
Kg
4,5
8
15
41
2863
Each 128,00 198,00 428,00 719,00
vuoto
PIPEWORKINGVICES
