217 / 1410
217
WRENCHES FOR METAL RINGS
3
Prices in EURO - VAT not included
217
842V
Product description as Art. 842R
For GU self-locking ring nuts, external toothing
Locking ring
nuts Ø
mm
18 22 25 28 32 38 44 50 56 62 68
Ø ring nuts
thread
mm 10x0,75 12x1 15x1 17x1 20x1 25x1,5 30x1,5 35x1,5 40x1,5 45x1,5 50x1,5
Teeth
Nr
4
4
4
4
4
4
4
4
4
4
4
Square drive inch 3/8 3/8 1/2 1/2 1/2 3/4 3/4 3/4 3/4 3/4 3/4
842V Each 35,40 36,40 37,40 39,30 43,20 44,20 45,20 46,20 48,20 52,10 57,10
vuoto
WRENCHESFORMETALRINGS
PERCUSSION WRENCHES
843G
843GP
Orig. Gedore - Art. 306
In forged CHROME VANADIUM steel up to a length of 435mm, in forged SPECIAL STEEL from a
length of 450mm. Single ended, bihexagonal. Grey sandblasted finish.
Heavy duty. For use with hammers or sledge hammers. Dimensions according to DIN 7444.
Opening
mm
22
24
27
30
32
34
36
38
41
46
50
55
60
65
70
Overall length
mm 160 160 180 190 195 195 205 205 225 240 250 270 270 290 320
Head thickness
mm 15
15 15,5 16,5 16,5 16,5 19,5 19,5 20,5 22,5 23,5 25
26
29 32,5
Weight
Kg 0,250 0,250 0,350 0,400 0,450 0,600 0,750 0,660 0,850 1,050 1,250 1,550 1,650 2,300 2,600
843G
Each 23,00 23,10 28,20 33,10 35,50 37,80 43,80 47,50 57,50 61,70 71,40 79,20 85,20 112,00 123,00
Opening
mm
75
80
85
90
95 100 105 110 115 120 125 130 135 140 145
Overall length
mm 325 345 360 400 400 400 435 435 435 480 480 520 520 520 580
Head thickness
mm 34
35
37 41,5 41,5 41,5 47,5 47,5 47,5 54
54
58
58
58
64
Weight
Kg 3,350 3,800 4,200 5,700 5,700 5,700 8,500 8,500 8,500 10,000 10,000 13,000 13,000 13,000 18,000
843G
Each 134,00 190,00 231,00 278,00 313,00 352,00 441,00 476,00 517,00 1.150,00 1.470,00 1.600,00 1.680,00 1.070,00 1.180,00
Opening
mm
150 155 160 165 170 175*
185*
190*
195*
210*
Overall length
mm 580 580 580 650 650 650 700 700 700 750
Head thickness
mm 64
64
64
70
70
70
75
75
75
80
Weight
Kg 18,000 18,000 18,000 25,000 25,000 32,000 32,000 32,000 32,000 40,000
843G
Each 1.300,00 1.420,00 1.570,00 1.720,00 1.890,00 2.890,00 3.140,00 3.140,00 3.140,00 3.590,00
Sizes 22 to 60 mm are supplied with UNIT DRIVE shaped opening.
When stocks are depleted, the size from 140 to 170 mm will become SCU instead of Gedore.
* Sizes running out of stock
vuoto
Product description as Art. 843G
MODEL WITH OPENINGS IN US INCH SIZES
Opening
inch
1 1.1/16 1.1/8 1.3/16 1.1/4 1.5/16 1.3/8 1.7/16 1.1/2 1.5/8 1.11/16 1.3/4 1.13/16 1.7/8 2 2.1/16 2.1/8
Overall length
mm 160 185 185 190 190 195 195 205 210 225 225 225 240 240 250 250 250
Head thickness
mm 15 15,5 15,5 16,5 16,5 16,5 16,5 19,5 20 20,5 20,5 20,5 22,5 22,5 23,5 23,5 23,5
Weight
Kg 0,250 0,350 0,350 0,400 0,400 0,450 0,450 0,750 0,725 0,850 0,850 0,850 1,050 1,050 1,250 1,250 1,320
843GP
Each 30,60 30,20 34,40 34,40 37,40 37,50 39,80 40,60 40,60 59,50 59,50 70,10 70,10 70,10 83,10 83,60 113,00
Opening
inch
2.3/16 2.1/4 2.3/8 2.7/16 2.9/16 2.5/8 2.3/4 3 3.1/8 3.3/8 3.1/2 3.3/4 3.7/8 4 4.1/8 4.1/2
Overall length
mm 270 270 270 270 290 290 320 325 345 360 390 400 420 420 420 450
Head thickness
mm 25 25 26 26 29 29 32,5 34 35 36 40 41,5 45 45 45
48
Weight
Kg 1,550 1,550 1,650 1,650 2,300 2,300 2,600 3,350 3,800 3,550 5,430 5,700 6,800 6,800 6,300 7,900
843GP
Each 109,00 109,00 109,00 111,00 139,00 139,00 151,00 160,00 257,00 341,00 375,00 549,00 665,00 761,00 781,00 1.190,00
Sizes 1 and 1.3/8 inch with UNIT DRIVE shaped opening.
When stocks are depleted, the size from 3.1/8 to 4.1/2 inches will become SCU instead of Gedore.
PERCUSSIONWRENCHES
PERCUSSION WRENCHES WITH SAFETY SPRING
843GT
new
843GV
new
Prod. SCU
Single ended type, with sturdy spring to prevent the fall of the tool, that one operator can use with
one hand and with hammer or mallet.
In special forged steel. Burnished finish. For heavy work. Dimensions according to DIN 7444.
Opening
mm
17 19 22 24 27 30 32 34 36
Overall length
mm 145 145 155 165 175 185 185 210 210
843GT
Each 29,60 32,10 40,80 47,70 54,10 64,70 71,60 76,80 87,20
Opening
mm
38 41 46 50 55 60 65 70
Overall length
mm 220 225 240 250 270 270 300 320
843GT
Each 92,40 99,30 114,00 125,00 146,00 171,00 204,00 245,00
vuoto
Product description as Art. 843GT
TYPE WITH OPENINGS IN US INCHES
Opening
inch
1/2 3/4 7/8 15/16 1 1.1/16 1.1/8 1.3/16 1.1/4 1.5/16 1.3/8 1.7/16 1.1/2 1.5/8 1.11/16
Overall length
mm 100 145 155 165 175 175 185 185 185 210 210 210 220 230 230
843GV
Each 41,60 32,10 36,40 40,20 43,50 47,30 54,40 55,70 61,60 67,80 74,60 82,10 90,70 93,90 97,60
Opening
inch
1.3/4 1.13/16 1.7/8 2 2.1/16 2.1/8 2.3/16 2.1/4 2.3/8 2.7/16 2.1/2 2.9/16 2.5/8 2.3/4
Overall length
mm 240 240 240 250 270 270 270 270 270 270 300 300 300 320
843GV
Each 101,00 99,50 110,00 124,00 138,00 152,00 166,00 176,00 197,00 201,00 205,00 212,00 227,00 250,00
vuoto
PERCUSSIONWRENCHESWITHSAFETYSPRING
