ELECTRONIC TORQUE WRENCH TESTERS
3
Prices in EURO - VAT not included
175
793GRA
Orig.Torqueleader - Art. 036700 CAPTURE DISPLAY + Art. 036246 CAVO
Display with clear digits of the CAPTURE system to measure the torque according to DIN EN ISO
6789 of screwdrivers and torque wrenches with R+L rotation; opportunity to download the results
of the tests on the computer via USB connection. Aluminium body, easy to use, simple to connect
via cable to the application sensors and to the rotary encoders of the torque tools. Ideal for use in
static control laboratories or for mobile use in the collection of data using the built-in memory and
a rechargeable Lithium battery. Chance to integrate with transducers with a standard 2 mlV/V
connection. Supplied in a sturdy and practical plastic box for transport and protection. Connection
cable to the sensors and to the transducers. Dimensions 170x140x80mm.
793GRA
Each 4.750,00
Available on request:
Replacement cables for connection to sensors and transducers Art. 793 GSA-B
(Art. 036246);
connecting cables to the transducers 2 MLV/V (Art. 036226).
When stocks will be run out, will be shipped the same item marked Gedore.
vuoto
ELECTRONICTORQUEWRENCHTESTERS
793GSA
Orig.Torqueleader - Art. CAPTURE SENSOR
Measurement sensors for the simple and fast transmission of the tightening force of the manual
torque tools to the control display Art. 793 GRA, via cable. Body in aluminium alloy, which can be
mounted horizontally or vertically. Supplied with UKAS certificate in accordance with BS 7882:
2008 Class 1 (English correspondent of the ACCREDIA certification), with robust and practical
plastic box for transport and protection.
Size
2
10
50
250
1500
Effective load capacity
Nm 0,2-2
1-10
5-50
25-250
150-1500
Square drive
inch
1/4
1/4
3/8
1/2
1
Weight
Kg
0,500
0,500
0,570
1,450
4
Supplier code.....................
CS 2
CS 10
CS 50
CS 250
CS 1500
793GSA
Each 2.550,00
2.580,00
2.600,00
2.930,00
4.440,00
Supplied on request:
Support for rapid sensor change (Art. 036 772).
When stocks will be run out, will be shipped the same item marked Gedore.
vuoto
ELECTRONICTORQUEWRENCHTESTERS
793GSB
1/4 ,,
Orig.Torqueleader
Accurate rotary measurement transducers for the simple and fast transmission of the tightening
force of the manual torque tools to the control display Art. 793 GRA, via cable. Stable metal body,
well-designed to avoid precision errors even in the presence of applications with strong vibrations.
Tolerance ± 0.3% on maximum force applied.
Size
2
5
20
Effective load capacity
Nm 0,2-2
0,5-5
2-20
Male/female hexagonal drive
inch
1/4
1/4
1/4
Max no. of revolutions / min continuous
5000
5000
5000
Max no. of revolutions / min intermittent
11000
11000
11000
Weight
Kg
0,210
0,210
0,210
Supplier code ....................................
XR 2 HD XR 5 HD XR 20HD
793GSB
Each 7.100,00 7.100,00 7.100,00
When stocks will be run out, will be shipped the same item marked Gedore.
vuoto
ELECTRONICTORQUEWRENCHTESTERS
793GSE
Orig.Torqueleader - Art. 036710 CAPTURE MANAGER
CAPTURE system software that allows for quick and easy analysis of the data of the tightening
torque tools thanks to integration with the system for PC MICROSOFT EXCEL®. It allows to store
an unlimited number of tools and data in the PC that can be uploaded and downloaded from the
DISPLAY Art. 793 GRA via USB connection.
The clear and simple use of this software allows you to perform tests according to ISO 6789: 2003
ensuring the proper operation of the torque tools. The same can also become traceable by
generating customizable calibration certificates according to the above mentioned regulations.
793GSE
Each 763,00
When stocks will be run out, will be shipped the same item marked Gedore.
