1206 / 1410
1206
Prices in EURO - VAT not included
1206
MILLS FOR SCREW SEATS WITH INTERCHANGEABLE GUIDES
13
8931GB
HSS
Orig. Dürr
Interchangeable guides DIN 1868 for mills Art. 8931 GA.
HSS.
Ø screw x Ø guide
M x mm
8x6,8
8x8,4
8x9
10x10,5
10x11
12x10,2
12x13
Guide Ø drive
mm
4
4
4
5
5
5
5
For mills Art.
8931GA 8
8931GA 8
8931GA 8 8931GA 10-12 8931GA 10-12 8931GA 10-12 8931GA 10-12
8931GB
Each
24,60
24,60
24,70
30,60
30,60
33,90
33,90
Ø screw x Ø guide
M x mm
12x13,5
14x12
14x15
14x15,5
16x17
16x17,5
18x15,5
Guide Ø drive
mm
5
6
6
6
8
8
8
For mills Art.
8931GA 10-12 8931GA 14
8931GA 14
8931GA 14 8931GA 16-18 8931GA 16-18 8931GA 16-18
8931GB
Each
33,90
39,40
39,40
39,40
41,70
41,70
41,70
Ø screw x Ø guide
M x mm
18x19
18x20
20x17,5
20x21
20x22
Guide Ø drive
mm
8
8
10
10
10
For mills Art.
8931GA 16-18 8931GA 16-18 8931GA 20
8931GA 20
8931GA 20
8931GB
Each
41,70
41,70
44,30
42,30
44,30
Product running out of stock
vuoto
MILLSFORSCREWSEATSWITH INTERCHANGEABLEGUIDES
COUNTERSINKS FOR 90° COUNTERSINK-HEAD SCREW SEATS (PASSING-THROUGH SCREWS)
8932A
HSS-E-5%
Prod. SCU
HSS-E COBALT 5% - DIN 1866.
For creating the seat to the 90° countersink head of passing-through screws.
For iron and high-resistance steel.
Cylindrical shank. FINE tolerance.
For screws
M.
3
4
5
6
8
10
Cutting edges Ø
mm 6,3
8,3
10,4
12,4
16,5
20,5
Guide Ø
mm 3,2
4,3
5,3
6,4
8,4
10,5
Drive Ø
mm 6
8
10
10
12
12
Overall length
mm 71
71
80
80
100
100
8932A
Each 41,90 45,50 56,30 68,60 85,50 123,00
vuoto
COUNTERSINKSFOR90°COUNTERSINK-HEADSCREWSEATS (PASSING-THROUGHSCREWS)
8932G
HSS
Orig. Dürr - Art. 212-11 / 212-21
HSS - DIN 1866.
For creating the seat to the 90° countersink head of passing-through screws.
For iron and high-resistance steel.
Cylindrical shank. FINE tolerance.
For screws
M.
2
2,5
3
4
5
6
8
Cutting edges Ø
mm 4,3
5
6
8
10 11,5 15
Guide Ø
mm 2,2
2,7
3,2
4,3
5,3
6,4
8,4
Drive Ø
mm 4,3
5
5
5
8
8
12,5
Overall length
mm 56
56
71
71
80
80
100
8932G
Each 61,70 61,70 52,10 57,70 62,10 74,40 105,00
vuoto
COUNTERSINKSFOR90°COUNTERSINK-HEADSCREWSEATS (PASSING-THROUGHSCREWS)
COUNTERSINKS FOR 90° COUNTERSINK-HEAD SCREW SEATS (SCREWS TO THREAD)
8934G
HSS
Orig. Dürr - Art. 212-21
HSS - DIN 1866.
For creating the seat to the 90° countersink head of screws to thread.
For iron and high-resistance steel.
Cylindrical shank. FINE tolerance.
For screws
M.
3
4
5
6
8
Cutting edges Ø
mm 6
8
10
11,5
15
Guide Ø
mm 2,5
3,3
4,2
5
6,8
Drive Ø
mm 5
5
8
8
12,5
Overall length
mm 71
71
80
80
100
8934G
Each 60,90 65,40 72,40 87,80 107,00
vuoto
COUNTERSINKSFOR90°COUNTERSINK-HEADSCREWSEATS (SCREWSTOTHREAD)
JET REAMERS
8940G
Prod. SCU
In hardened steel. Ground cutting edges.
For soft metal, iron, steel up to R 80/90 Kg.
Size
75
74
72
71
70
68
66
65
64
62
60
58
56
55
53
Max Ø
mm 0,5 0,55 0,6 0,65 0,7 0,75 0,8 0,85 0,9 0,95
1
1,1 1,2 1,3 1,5
Useful length
mm 35
35
40
40
40
40
40
45
48
48
55
55
55
55
60
8940G
Each 1,88 1,88 1,88 1,88 1,88 1,88 1,88 1,88 1,88 1,88 1,88 1,96 2,14 2,04 2,44
Size
52
50
48
46
39
31 28*
21*
15*
8*
6*
5*
4*
3*
2*
Max Ø
mm 1,6 1,7 1,9
2
2,5
3
3,5
4
4,5
5
6
7
8
9
10
Useful length
mm 60
70
70
70
75
80
85
90
95 100 110 110 125 130 130
8940G
Each 2,44 2,56 3,44 3,44 4,28 5,18 4,98 6,76 7,90 9,26 12,40 15,10 19,20 24,70 32,10
* Sizes running out of stock
vuoto
JETREAMERS
