1203 / 1410
1203
Prices in EURO - VAT not included
1203
COUNTERBORES FOR TAPERED-HEAD SCREW SEATS (PASSING-THROUGH SCREWS)
13
COUNTERBORES FOR TAPERED-HEAD SCREW SEATS (PASSING-THROUGH SCREWS)
8915A
HSS-E-5%
Prod. SCU
HSS-E COBALT 5% - DIN 373.
For creating the seat to the tapered head of internal hexagonal passing-through screws.
For iron and high-resistance steel.
Cylindrical shank. FINE tolerance.
For screws
M.
3
4
5
6
8
10
12
14
Cutting edges Ø
mm 5,9
7,4
8,9 10,4 13,5 16,5 19
22
Guide Ø
mm 3,2
4,3
5,3
6,4
8,4 10,5 13
15
Drive Ø
mm 6
6
8
8
12
12
12
16
Overall length
mm 71
71
80
80
100 100 100 130
8915A
Each 25,50 26,50 29,30 30,90 36,50 43,70 54,70 70,90
vuoto
COUNTERBORESFORTAPERED-HEADSCREWSEATS (PASSING-THROUGHSCREWS)
8915G
HSS
Orig. Dürr - Art. 211-21
HSS – DIN 373.
For creating the seat to the tapered head of internal hexagonal passing-through screws.
For iron and high-resistance steel.
Cylindrical shank. FINE tolerance.
For screws
M.
3
4
5
6
8
10
12
Cutting edges Ø
mm 6
8
10
11
15
18
20
Guide Ø
mm 3,2
4,3
5,3
6,4
8,4 10,5 13
Drive Ø
mm 5
5
8
8
12,5 12,5 12,5
Overall length
mm 71
71
80
80
100 100 100
8915G
Each 22,40 19,90 21,60 22,80 37,10 44,60 50,10
vuoto
COUNTERBORESFORTAPERED-HEADSCREWSEATS (PASSING-THROUGHSCREWS)
8915GM
HSS
HSS – DIN 373.
For creating the seat to the tapered head of internal hexagonal passing-through screws.
For iron and high-resistance steel.
Cylindrical shank. MEDIUM tolerance.
Type
mm
3
4
4L 4XL 5
5L 5XL 6
For screws
M.
3
4
4
4
5
5
5
6
Cutting edges Ø
mm 6
8
8
8
10
10
10
11
Guide Ø
mm 3,4
4,5
4,5
4,5
5,5
5,5
5,5
6,6
Drive Ø
mm 5
5
5
5
8
8
8
8
Overall length
mm 71
71
150 200
80
150 200
80
8915GM
Each 21,90 19,60 298,00 315,00 21,30 301,00 318,00 22,50
Type
mm
6XL 8
8XL 10 10XL 12 12XL
For screws
M.
6
8
8
10
10
12
12
Cutting edges Ø
mm 11
15
15
18
18
20
20
Guide Ø
mm 6,6
9
9
11
11 13,5 13,5
Drive Ø
mm 8
12,5 12,5 12,5 12,5 12,5 12,5
Overall length
mm 200 100 200 100 200 100 200
8915GM
Each 321,00 36,60 338,00 44,10 355,00 48,90 392,00
On request, the cutters Art. 8915 G - 8915 GM are available in STEEL SUPER-FAST COBALT 10% HSS-E.
vuoto
COUNTERBORESFORTAPERED-HEADSCREWSEATS (PASSING-THROUGHSCREWS)
COUNTERBORES FOR TAPERED-HEAD SCREW SEATS (SCREWS TO THREAD)
8918G
HSS
Orig. Dürr - Art. 211-21
HSS – DIN 373.
For creating the seat to the tapered head of internal hexagonal screws to thread.
For iron and high-resistance steel.
Cylindrical shank.
For screws
M.
3
4
5
6
8
10
Cutting edges Ø
mm 6
8
10
11
15
18
Guide Ø
mm 2,5
3,3
4,2
5
6,8
8,5
Drive Ø
mm 5
5
8
8
12,5 12,5
Overall length
mm 71
71
80
80
100 100
8918G
Each 25,80 24,70 26,70 28,20 40,40 49,20
COBALT 10% HSS-E Mills Art. 8915 G - 8915 GM and 8918 G available on request.
vuoto
COUNTERBORESFORTAPERED-HEADSCREWSEATS (SCREWSTOTHREAD)
COUNTERBORES FOR TAPERED-HEAD SCREW SEATS (PASSING-THROUGH SCREWS)
8921G
HARTMETALL
Orig. Dürr - Art. 211-23
In integral HARD METAL (except size 8 with only the head in hard metal). Similar to DIN 373.
For creating the seat to the tapered head of internal hexagonal passing-through screws.
For steel and difficult to chip materials, cast iron, aluminium-silicium alloys and stainless steel.
Cylindrical shank. FINE tolerance.
For screws
M.
3
4
5
6
8
Cutting edges Ø
mm 6
8
10
11
15
Guide Ø
mm 3,2
4,3
5,3
6,4
8,4
Drive Ø
mm 5
6
8
8
12,5
Overall length
mm 71
71
80
80
100
8921G
Each 307,00 316,00 333,00 356,00 484,00
Product running out of stock
vuoto
COUNTERBORESFORTAPERED-HEADSCREWSEATS (PASSING-THROUGHSCREWS)
