1006 / 1410
1006
Prices in EURO - VAT not included
1006
DIGITAL ELECTRONIC DYNAMOMETERS
11
4488A
new
High-quality, digital type, low weight, compact size, sturdy, with testing and safety requirements
according to European standards EN 13155 / EN 61010 and German standards TÜV-GS.
Aluminum body with stainless steel bushings for capacities up to Kg 600-1000-3000, steel body
for capacities up to Kg 5000 and 10000. With LCD display, backlit, 5 digits (digits height: 23 mm),
HOLD button for prolonged reading of the weight, ON / OFF-UNIT button for switching the device
on and off and for selecting, and with TARE button to entry the tare. Operated by internal storage
unit, autonomy ca. 30 hours without using the backlight, charging time about 12 hours using 240
V power supply, supplied. It can also work with 3 alkaline AA batteries (see Art. 3600 E), not
supplied.
Accuracy: ± 0.2% of maximum scale value.
Supplied without shackles and without hook.
Capacity up to
Kg
600
1000
3000
5000
10000
Division
Kg
0,2
0,5
1
2
5
Overall height (D)
mm 255
255
255
255
275
Bores distances ©
mm 165
165
165
165
175
Bore Ø (A-B)
mm 27
27
27
30
40
Width (E)
mm 90
90
90
90
90
Plate thickness (F)
mm 30
30
30
30
40
Overall thickness (G)
mm 55
55
61
61
71
Weight
Kg
1,8
1,8
1,8
3,9
5,5
4488A
Each 1.200,00
1.400,00
1.520,00
1.600,00
2.110,00
For lifting hooks and shackles see Art. 2133 V to 2133 ZE and 2157E.
On request we supply dynamometers from 1,000 Kg up to 10,000 with the same characteristics,
but with viewer / separate display for remote data viewing.
vuoto
DIGITALELECTRONICDYNAMOMETERS
4488B
Digital model for tension and compression measurements, sturdy and user-friendly.
5-digits LCD display (digits height 27mm), ON/OFF key, MAX key for peak measurements, UNIT
key for unit of measure selection (N-Kgf-lbf-oz) and automatic conversion of the values, ZERO key
for measurement reset.
High-frequency data recording (1000 Hz). Uncertainty of measurement ± 0.5% of the max. value.
Overload protection 200% of the peak value. No.6 alkaline batteries 1.5V, rechargeable and 230V
- 50Hz feeder (included). Automatic switch-off.
Supplied with No.6 interchangeable tools (5 heads + 1 extension 90mm).
Weight 0.600kg. Dimensions 195x84x35mm.
In package.
Capacity up to
N
50
100
250
500
1000
Division
N
0,02
0,05
0,1
0,2
0,5
4488B
Each 420,00
420,00
420,00
420,00
420,00
vuoto
DIGITALELECTRONICDYNAMOMETERS
4488E
Digital model for tension and compression measurements, high-precision for high performances.
With data output RS 232.
Backlit LCD display, 5-digit. ON/OFF key, PEAK key for peak measurements, UNIT key for unit of
measure selection (N-Kgf-lbf) and automatic value conversion, ZERO key for measurement reset,
SET key for measuring range verification and remote data transfer, MEMORY key to store up to 10
detected values, PRINT key for data transfer and printing.
High-frequency data recording (2000 Hz). Uncertainty of measurement ± 0.2% of max. value.
Overload protection 150% of max. value. Statistcs function able to generate the average value of the
measured values as well of the max and min load peaks.
Rechargeable battery and 220V - 50Hz feeder (included). Automatic switch-off.
Supplied with No.6 interchangeable tools (5 heads + 1 extension 90mm).
Weight 0.640kg. Dimensions 238x63x36mm.
In case.
Capacity up to
N
5
10
20
50
100
200
500
Division
N 0
,001 0,005 0,010 0
,010 0,050 0,100 0,10
4488E
Each 773,00 773,00 773,00 773,00 773,00 773,00 773,00
vuoto
DIGITALELECTRONICDYNAMOMETERS
4488F
MANUAL SUPPORT FOR TORQUE WRENCHES ART. 4487 GE - 4488 B - 4488 E
Compact and robust support, rapid movement, lever-operated. It guarantees ample measurement
excursions, high versatility, fast measurement repetition, several tests available.
Load up to 500 N, wide and stable base provided with drilled plate for wall installation.
Min. plate height 115mm.
Max height above plate 318mm.
Length of stroke at each lever turn 78mm.
Weight 10.5kg. Dimensions 233x150x420mm.
4488F
Each 521,00
