210
TORQUE WRENCHES WITH MALE DRIVE
210
3
Prices in EURO - VAT not included
809GA
809GB
809GC
16
Orig. Gedore
Click type. Light alloy body. Inside components in alloyed steel. ± 3% tolerance of the scale set
torque. Double scale Nm/lbf on handle. Adjustment by means of the jointed socket built-in in the
handle. Audible acustic signal ("click") on reaching preset torque value. For controlled bi-
directional tightening.
Supplied with test certificate as per DIN ISO 6789.
Type with straight connection with male pin.
Art.
809GA
809GB
809GC
Pivot drive Ø
mm
16
16
16
Tightening capacity
Nm 8-40
20-120
50-400
Tightening capacity
lbf.in
70-350
-
-
Tightening capacity
lbf.ft
-
15-90
35-300
Scale division
5 Nm/50 lbf.in 5 Nm/5 lbf.ft
5 Nm/5 lbf.ft
Overall length
mm 365
490
642
Weight
Kg
1
1,45
2
Supplier code
8460-01
8461-01
8462-01
Each 580,00
645,00
807,00
vuoto
TORQUEWRENCHESWITHMALEDRIVE
809GD
22
Orig. Gedore - Art. 8463-10
Product description as Art. 809GA
Pivot drive Ø
mm
22
Tightening capacity
Nm 140-620
Tightening capacity
lbf.ft
105-450
Scale division
10 Nm/10 lbf.ft
Overall length
mm 845
Weight
Kg
3
809GD
Each 1.540,00
vuoto
TORQUEWRENCHESWITHMALEDRIVE
809GE
28
Orig. Gedore - Art. 8471-01
Product description as Art. 809GA
Pivot drive Ø
mm
28
Tightening capacity
Nm 520-1000
Tightening capacity
lbf.ft
380-730
Scale division
10 Nm/10 lbft.ft
Overall length
mm 845
Weight
Kg
3
809GE
Each 2.180,00
Art. 809 GE: supplied with bar. Wrench overall length: 1330mm.
vuoto
TORQUEWRENCHESWITHMALEDRIVE
BITS WITH 16 MM DIAMETER FEMALE COUPLING
809GF
16
Orig. Gedore
Made from CHROME-VANADIUM steel.
For all torque wrenches with male Ø 16mm connector.
Open end fitting.
Opening
mm
7
8
9
10
11
12
13
809GF
Each 55,10 55,10 55,10 55,10 55,10 55,10 55,10
Opening
mm
14
15
16
17
18
19
20
809GF
Each 55,10 55,10 55,10 55,10 55,10 55,10 55,10
Opening
mm
21
22
23
24
25
26
27
809GF
Each 59,10 59,10 59,10 59,10 59,10 64,40 64,40
Opening
mm
28
29
30
32
36
809GF
Each 64,40 64,40 64,40 64,40 64,40
Inch sizes are available on request.
vuoto
BITSWITH 16MMDIAMETERFEMALECOUPLING
809GH
16
Product description as Art. 809GF
Bihexagonal ring end fitting.
Opening
mm
7
8
9
10
11
12
13
809GH
Each 57,50 57,50 57,50 57,50 57,50 57,50 57,50
Opening
mm
14
15
16
17
18
19
20
809GH
Each 57,50 57,50 57,50 57,50 57,50 57,50 57,50
Opening
mm
21
22
23
24
27
809GH
Each 60,10 60,10 60,10 60,10 60,10
Inch sizes are available on request.
vuoto
BITSWITH 16MMDIAMETERFEMALECOUPLING
