209
TORQUE WRENCHES WITH MALE DRIVE
209
3
Prices in EURO - VAT not included
TORQUE WRENCHES WITH MALE DRIVE
808GA
16
Orig. Torqueleader - Art. ATB 25
Model with high precision tightening on pre-set torque value.
Sturdy finish for long-lasting serial tightening. ± 4% tolerance of the scale set torque.
Automatic disconnection through angled movement at 20° of the rod. Automatic rest.
Scale with graduation Nm with value clear reading.
Adjustment obtained by rotating the ergonomically shaped soft rubber handgrip, safety lock at the
extremity. For controlled bi-directional tightening.
Supplied with test certificate as per DIN ISO 6789.
With straight connection with male pin
Pivot drive Ø
mm 16
Tightening capacity
Nm 5-25
Scale division
0,1 Nm
Overall length
mm 297
Weight
Kg 0,68
808GA
Each 270,00
Product running out of stock.
vuoto
TORQUEWRENCHESWITHMALEDRIVE
808GL
808GP
808GR
808GS
808GT
808GV
new
16
Orig. Gedore
Click type. Handy construction. Adjustment obtained by rotating the ergonomically shaped nylon
handgrip, safety lock at the extremity.± 3% tolerance of the scale set torque.
Double scale with graduation Nm/lbf.ft on handle below a window with a magnifying-glass effect
that makes reading easier. For controlled bi-directional tightening.
Supplied with test certificate as per DIN ISO 6789.
Art.
808GL 808GP 808GR 808GS 808GT 808GV
Pivot drive Ø
mm 16
16
16
16
16
16
Tightening capacity
Nm 2-25
5-50
10-100 20-200 60-300 75-400
Tightening capacity
lbf.ft
1,5-18 3,5-37
8-75
15-150 45-220 55-300
Scale division
0,1 Nm 0,25 Nm 0,5 Nm 1 Nm 1 Nm 1 Nm
Overall length
mm 279
329
377
468
559
646
Weight
Kg
0,33
0,39
0,7
0,86
1,08
1,39
Supplier code
4400-02 4405-05 4410-01 4420-01 4430-01 4440-01
Each 193,00 202,00 222,00 256,00 294,00 407,00
vuoto
TORQUEWRENCHESWITHMALEDRIVE
808H
16
Orig. Gedore - Dremaster Z
Release type model.
Easy to handle. Can be adjusted by rotating the ergonomic handle with safety lock, which
includes visual monitoring located at the far end. An additional quick adjustment is also possible
by using round tenders, although these are not provided. Dual component handle with soft, non-
slip grip with a clear path through to the centre providing an accurate hold and an accurate
calibration process. Tolerance: ± 3% for each scale reading. Dual scale Nm/lbf.ft reading which
can be selected by using the cursor, and which helps to avoid any potential reading errors.
Micrometric adjustments with Nm values.
Equipped with items certified as per DIN ISO 6789:2003.
Type II, Class A.
Type with straight coupling with male pin.
Size
100
200
300
400
Pivot drive Ø
mm 16
16
16
16
Tightening capacity
Nm 20-100 40-200 60-300 80-400
Tightening capacity
lbf.ft
15-75 30-150 45-220 60-300
Scale division
0,5 Nm 1 Nm 1 Nm 1 Nm
Overall length
mm 405,5
496,5
587,5
677,5
Weight
Kg
0,9
1,1
1,3
2,2
Supplier code
DMZ 100 DMZ 200 DMZ 300 DMZ 400
808H
Each 259,00 298,00 342,00 475,00
Wrenches Art. 808 H with inserts and ratchets can be supplied on request in a metal case.
vuoto
TORQUEWRENCHESWITHMALEDRIVE
808M
22
Product description as Art. 808H
Type with straight coupling with male pin.
Size
550
750
850
Pivot drive Ø
mm 22
22
22
Tightening capacity
Nm 110-550 150-750 250-850
Tightening capacity
lbf.ft
80-405 110-550 185-630
Scale division
1 Nm 1 Nm 1 Nm
Overall length
mm 913
1194
1341
Weight
Kg
3,6
4,7
5
Supplier code
DMZ 550 DMZ 750 DMZ 850
808M
Each 812,00 944,00 1.370,00
