1165
SINUSOIDAL END MILLS
1165
13
Prices in EURO - VAT not included
8758F
HSS-E-8%
Sinusoidal flute end mills. Very high performance, vibration reduction, better chip ejection, less
absorbed power, lower sound level, excellent finishing of the processed surface, longer life, higher
speed and feed rates. Long series. Weldon shank. Cutting tolerance J14.
Ø 12mm=3 flute/Ø 16 and 20mm=4 flute/Ø 25mm= 5 flute/Ø 30mm=6 flute
HSS-E COBALT 8%
Ø
mm
12
16
20
25
30
Overall length
mm 110
123
141
166
166
Cutting edge length
mm 53
63
75
90
90
Drive Ø
mm 12
16
20
25
25
8758F
Each 68,50 99,10 140,00 206,00 286,00
SINUSOIDALENDMILLS
8758L
HSS-E-8%
TiAIN
Product description as Art. 8758F
HSS-E COBALT 8%, TiAIN coating.
Ø
mm
12
16
20
25
30
Overall length
mm 110
123
141
166
166
Cutting edge length
mm 53
63
75
90
90
Drive Ø
mm 12
16
20
25
25
8758L
Each 97,20 143,00 201,00 296,00 409,00
vuoto
SINUSOIDALENDMILLS
8758R
HSS-E-8%
TiCN
Sinusoidal flute end mills. Very high performance, vibration reduction, better chip ejection, less
absorbed power, lower sound level, excellent finishing of the processed surface, longer life, higher
speed and feed rates. Short series. Morse taper shank and threaded hole. Cutting tolerance J14.
Ø 16 and 20mm=4 flute/Ø 25mm=5 flute/Ø 30 and 40mm= 6 flute
HSS-E COBALT 8%, TiCN coating.
Ø
mm
25
30
35
Overall length
mm 147
147
178
Cutting edge length
mm 45
45
53
Drive
C.M.
3
3
4
8758R
Each 249,00 341,00 547,00
Product running out of stock.
SINUSOIDALENDMILLS
8758T
HSS-E-8%
TiCN
Sinusoidal flute end mills. Very high performance, vibration reduction, better chip ejection, less
absorbed power, lower sound level, excellent finishing of the processed surface, longer life, higher
speed and feed rates. Long series. Morse taper shank and threaded hole. Cutting tolerance J14.
Ø 16 and 20mm=4 flute/Ø 25mm=5 flute/Ø 30 and 40mm= 6 flute
HSS-E COBALT 8%, TiCN coating.
Ø
mm
16
30
Overall length
mm 148
192
Cutting edge length
mm 63
90
Drive
C.M.
2
3
8758T
Each 202,00 476,00
Product running out of stock.
SINUSOIDALENDMILLS
ONE FLUTE MILLS
8759
HSS-E-5%
Prod. SCU
Single fluted mills. HSS-E COBALT 5%.
Cylindrical shank. For milling aluminium and synthetic materials.
To be used on pantographs and copying mills.
Ø
mm
3
4
5
6
8
10
Overall length
mm 60
60
70
70
80
95
Cutting edge length
mm 15
15
15
15
15
15
Drive Ø
mm 8
8
8
8
8
8
8759
Each 20,10 19,20 19,20 19,20 23,50 37,60
ONEFLUTEMILLS
SHELL-END MILLS
8761
HSS-E-8%
Prod. SCU
Spiral flute end mills for SEMI-FINISHING. Short series.
DIN 844 A – UNI 8244 A – ISO 1641/1. Weldon shank. Cutting tolerance J14.
Ø 6 to 22mm=4 flute/Ø 25-30mm=5 flute
HSS-E COBALT 8%
Ø
mm
8
10
12
14
15
16
18
Overall length
mm 69
72
83
83
83
92
92
Cutting edge length
mm 19
22
26
26
26
32
32
Drive Ø
mm 10
10
12
12
12
16
16
8761
Each 40,60 40,60 44,50 50,40 58,60 59,30 66,10
Ø
mm
20
22
25
30
Overall length
mm 104
104
121
121
Cutting edge length
mm 38
38
45
45
Drive Ø
mm 20
20
25
25
8761
Each 74,60 102,00 116,00 150,00
SHELL-ENDMILLS
