1163 / 1378
1163
END MILLS
1163
13
Prices in EURO - VAT not included
8749F
HSS-E-8%
Product description as Art. 8749
HSS-E COBALT 8%
Ø
mm
15
16
18
20
22
24
25
Overall length
mm 117
117
117
123
140
147
147
Cutting edge length
mm 32
32
32
38
38
45
45
Drive
C.M.
2
2
2
2
3
3
3
8749F
Each 66,60 66,60 67,50 86,70 95,80 105,00 108,00
Ø
mm
30
32
Overall length
mm 147
178
Cutting edge length
mm 45
53
Drive
C.M.
3
4
8749F
Each 134,00 179,00
vuoto
ENDMILLS
SHELL-END MILLS
8751
HSS-E-8%
Prod. SCU
Spiral flute end mills. Short series. DIN 844 A - UNI 8244 - ISO 1641/1.
Weldon shank. Cutting tolerance J14.
Ø 3 to 22mm = 4 flute/Ø 25 and 28mm = 5 flute/Ø 30mm = 6 flute
HSS-E COBALT 8%
Ø
mm
3
4
5
6
7
8
9
10
Overall length
mm 52
55
57
57
66
69
69
72
Cutting edge length
mm 8
11
13
13
16
19
19
22
Drive Ø
mm 6
6
6
6
10
10
10
10
8751
Each 14,30 14,30 15,90 15,90 20,30 20,30 23,40 23,40
Ø
mm
11
12
13
14
15
16
17
18
Overall length
mm 79
83
83
83
83
92
92
92
Cutting edge length
mm 22
26
26
26
26
32
32
32
Drive Ø
mm 12
12
12
12
16
16
16
16
8751
Each 27,90 27,90 32,40 32,40 41,40 41,40 45,20 45,20
Ø
mm
19
20
22
25
28
30
Overall length
mm 92
104 104 121 121 121
Cutting edge length
mm 32
38
38
45
45
45
Drive Ø
mm 20
20
20
25
25
25
8751
Each 56,50 56,50 70,70 78,70 98,00 110,00
vuoto
SHELL-ENDMILLS
8751E
HSS-E-8%
TiAIN
Product description as Art. 8751
HSS-E COBALT 8%, TiAIN coating.
Ø
mm
4
5
6
8
10
12
14
Overall length
mm 55
57
57
69
72
83
83
Cutting edge length
mm 11
13
13
19
22
26
26
Drive Ø
mm 6
6
6
10
10
12
12
8751E
Each 30,10 30,10 30,10 40,60 45,20 60,90 67,70
Ø
mm
16
18
20
Overall length
mm 92
92
104
Cutting edge length
mm 32
32
38
Drive Ø
mm 16
16
20
8751E
Each 88,70 94,90 113,00
vuoto
SHELL-ENDMILLS
8753
HSS-E-8%
Four-flute end mills. Long series. UNI 8245 A-ISO 1641/1.
Weldon shank. Cutting tolerance J14.
HSS-E COBALT 8%
Ø
mm
3
4
5
6
7
8
9
Overall length
mm 56
63
68
68
80
88
88
Cutting edge length
mm 12
19
24
24
30
38
38
Drive Ø
mm 6
6
6
6
10
10
10
8753
Each 20,10 20,10 20,10 20,10 27,90 27,90 30,80
Ø
mm
10
11
12
13
14
15
16
Overall length
mm 95
102
110
110
110
110
123
Cutting edge length
mm 45
45
53
53
53
53
63
Drive Ø
mm 10
12
12
12
12
16
16
8753
Each 30,80 35,40 35,40 41,50 41,50 51,10 51,10
Ø
mm
17
18
19
20
22
Overall length
mm 123
123
123
141
151
Cutting edge length
mm 63
63
63
75
75
Drive Ø
mm 16
16
20
20
20
8753
Each 69,10 62,30 79,60 71,80 90,10
vuoto
SHELL-ENDMILLS
