AIR RIVETERS
105
2
Prices in EURO - VAT not included
504GC
Prod. SCU
Oleo-pneumatic type, light and easy to handle for maintenance work.
Light alloy body, steel operating parts, handle made from insulating material.
1/4" GAS female air connection (for standard snap-on coupling see Art. 3478 D 1/4). Working
pressure 6.5 Atm. With rivet retainer and plastic tank for collection of small waste part.
For aluminium rivets up to Ø 4.8mm.
For copper, steel, STAINLESS steel rivets up to Ø 4mm.
Length
mm 300
Weight
Kg 1,450
504GC
Each 580,00
vuoto
AIRRIVETERS
504GE
Prod. Pneutec - Art. UT6DPP
Oleo-pneumatic type, strong and long-lasting. Light alloy body, steel operating parts.
R 1/4 air connection. Operating pressure 6.3 Atm. With plastic tank for the collection of small
waste parts.
For rivets (copper and aluminium only) up to Ø 6.4mm.
Length
mm 310
Air consumption
l/sec 1,7
Noise level
dB 77
Vibrations
m/sec²
4,8
Weight
Kg 2,100
504GE
Each 658,00
vuoto
AIRRIVETERS
504GL
Prod. SCU
Oleo-pneumatic type, strong and long-lasting.
Light alloy body, steel operating parts, handle made from insulating material.
1/4" GAS female air connection (for standard snap-on coupling see Art. 3478 D 1/4). Working
pressure 6.5 Atm. With rivet retainer and plastic tank for collection of small waste part.
For aluminium rivets up to Ø 6mm.
For copper, steel, stainless steel rivets up to Ø 4.8mm.
Length
mm 310
Weight
Kg 1,550
504GL
Each 703,00
Hydropneumatic rivetes for aluminium rivets up to 7.8mm, STAINLESS steel rivets up to 6.4 mm
and unibolt …rivets available on request.
vuoto
AIRRIVETERS
AIR RIVETERS
505
Prod. SCU
Professional type.
In die-cast aluminium body, steel operating parts.
1/4" Gas female coupling (for standard quick coupling, see Art. 3478 D 1/4").
With 4 heads. Use pressure 6 Atm.
For aluminium rivets up to Ø mm. 4,8
For copper, steel, stainless steel rivets up to Ø mm. 4.
Length
mm 210
Weight
Kg 1,500
505
Each 240,00
vuoto
AIRRIVETERS
