921 / 1410
921
Prices in EURO - VAT not included
921
ELECTRONIC ANGLE MEASURING DEVICES
11
ELECTRONIC ANGLE MEASURING DEVICES
4186F
Prod. SCU
Aluminium profile with 2 unbreakable bubbles, horizontal and vertical.
Electronic inclination measuring instrument with display reading in degrees. Division 0.1°.
With ON/OFF key, HOLD key to store the measurement and key for the display backlight.
For angles from 0° to 225°, accuracy ± 0.057 °.
With lock knob.
Operation with 9 V battery (Art. 3600 M), included.
Length of spirit level: 400 mm.
In case.
4186F
Each 80,70
vuoto
ELECTRONICANGLEMEASURINGDEVICES
4186G
Orig. Richter - Art. 3033
Professional typem, profiled in duralumin, 2 vials in shock-proof material, horizontal and vertical.
Accuracy 0.5 mm/m. Digital angle mesuring device with direct display reading in degrees and
percent. Increments in 0.05°. With ON / OFF key, HOLD key for storing the measurement, beep
key for angle 0 ° and 90 °, key for conversion degrees / percentage and calibration key
Accuracy of slope measuring device:
±0.5° for 0° to 90° angles
±20° for 1° to 89° angles
9 V battery operated (Art. 3600 M) included.
Length: 600mm. In case.
4186G
Each 434,00
vuoto
ELECTRONICANGLEMEASURINGDEVICES
LASER SPIRIT LEVELS
4186GL
Prod. SCU
Laser level in sturdy duralumin tube. 2 vials in shock-proof material, horizontal and rotating.
650nm wave length laser, power 1 mW.
Measuring range approx. 30m (depends on ambient light).
2 x AAA (Art. 3600 C) alkaline batteries. Vial accuracy: 0.5 mm/m. Length: 400mm. Ideal for rapid
and precise alignements on long distances.
Supplied complete with rotating base support, 1200mm tripod and glasses.
Delivered in plastic case.
4186GL
Each 129,00
vuoto
LASERSPIRIT LEVELS
TURNING LASER SPIRIT LEVELS
4186GR
Prod. SCU
Laser level for horizontal and vertical alignements, with 3 vials in shock-proof material, 2
horizontals, 1 vertical.
Rotating base support for easy, continuous alignement and 360° marking.
Operated by 4 alkaline batteries type AA (Art. 3600 E), supplied. Rotation speed: 0-500 rpm.
650mn wave length laser, power 1 mW (Class 2).
Measurement range approx. 10m (depending on brightness).
0.5 mm/m alignement precision.
Supplied with 1200mm tripod and protection glasses.
In plastic case.
4186GR
Each 185,00
vuoto
TURNING LASERSPIRIT LEVELS
4186GRE
Professional grade laser for horizontal and vertical alignments. With unbreakable bubbles and 3
manual levelling system. Movement powered by 4 AA alkaline batteries (3600 s), supplied.
Remote to remote control, carried out by a single operator, with 9 V alkaline battery (3600 M),
supplied.
Rotational speed 100-300 RPM. Laser beam with wavelength 635 nm, 1 mW power (class 2).
Measuring capacity
c.ca10 m (depends on the brightness of light); with receiver up to 100 m,
working with 9 V alkaline battery (3600 M), supplied.
Accuracy ± 0.2 mm/m for horizontal measurements.
Accuracy ± 0.3 mm/m for vertical measurements.
Complete with glasses to highlight the Laser beam.
Sturdy plastic case.
Weight
Kg 0,85
4186GRE
Each 2.380,00
vuoto
TURNING LASERSPIRIT LEVELS
