HOSE CLAMPS WITH RUBBER
10
HOSE CLAMPS WITH RUBBER
3474M
Prod. SCU
Type in W1 galvanized steel, smooth band with raised edges and hex-end screw. The bolt is
directly fixed on the threaded barrel, therefore collars can be tighten with electric or pneumatic
screwdrivers.
Ensure high clamping capacities. To be employed in agruculture, building, hydraulic sectors, etc.
Capacity Ø
mm
23-25 26-28 29-31 32-35 36-39 40-43 44-47
Screw
M 6
6
6
6
6
6
6
Belt width x thickness
mm 20x0,6 20x0,6 20x0,6 20x0,6 20x0,6 20x0,6 22x0,8
3474M
Each 1,36
1,36
1,40
1,44
1,82
1,88
1,88
Capacity Ø
mm
48-51 52-55 56-59 60-63 64-67 68-73 74-79
Screw
M 6
6
6
6
6
8
8
Belt width x thickness
mm 22x0,8 22x0,8 22x0,8 22x0,8 22x0,8 22x0,8 22x0,8
3474M
Each 1,90
1,92
1,94
2,00
2,02
2,14
2,18
Capacity Ø
mm
80-85 86-91 92-97 98-103 104-112 113-121 122-130
Screw
M 8
8
8
8
8
8
8
Belt width x thickness
mm 24x0,8 24x0,8 24x0,8 24x0,8 24x0,8 24x0,8 24x0,8
3474M
Each 2,26
2,30
2,34
2,36
2,44
2,74
3,78
Capacity Ø
mm
131-139 140-148 149-161 162-174 175-187 188-200
Screw
M 10
10
10
10
10
10
Belt width x thickness
mm 26x1 26x1 26x1 26x1 26x1 26x1
3474M
Each 3,86
3,98
4,16
4,20
4,32
4,62
When the stocks will be run out we will provide the steel version INOX 430, W2.
vuoto
HOSECLAMPSWITHRUBBER
3474ME
INOX
Type made entirely from stainless steel INOX 304, W 4. Smooth band with raised edges and hex
screw. The bolt is directly fixed on the threaded barrel, so that collars can be tightened with
electric or pneumatic screwdrivers.
Ensure high clamping capacities. Particularly suitable for nautical and food sectors.
Capacity Ø
mm
23-25 26-28 29-31 32-35 36-39 40-43 44-47
Screw
M 6
6
6
6
8
8
8
Belt width x thickness
mm 21x0,8 21x0,8 21x0,8 21x0,8 21x0,8 21x0,8 21x0,8
3474ME
Each 3,64
3,64
3,64
3,64
6,02
6,06
6,12
Capacity Ø
mm
48-51 52-55 56-59 60-63 64-67 68-73 74-79
Screw
M 8
8
8
8
8
8
8
Belt width x thickness
mm 21x0,8 21x0,8 21x0,8 21x0,8 21x0,8 24x1,2 24x1,2
3474ME
Each 6,16
6,20
6,30
6,34
6,38
6,44
6,48
Capacity Ø
mm
80-85 86-91 92-97 98-103 104-112 113-121 122-130
Screw
M 8
8
8
8
8
8
8
Belt width x thickness
mm 24x1,2 24x1,2 24x1,2 24x1,2 24x1,2 24x1,2 24x1,5
3474ME
Each 6,54
6,62
6,72
6,76
6,80
6,86
6,90
Capacity Ø
mm
131-139 140-148 149-161 162-174 175-187 188-200
Screw
M 8
8
8
8
8
8
Belt width x thickness
mm 26x1,5 26x1,5 26x1,5 26x1,5 26x1,5 26x1,5
3474ME
Each 7,04
7,12
7,22
7,32
7,40
7,54
vuoto
HOSECLAMPSWITHRUBBER
BAND, HOSE CLAMPS
3474PA
Prod. SCU
Assorted sets of No. 100 hose clamps Art. 3474 BN, in practical case Art. 2083 T 10.
Empty compartments are provided to allow the customer to add new items to his set.
The set consists of:
No.20 hose clamps Art. 3474 BN 8-12
No.30 hose clamps Art. 3474 BN 10-16
No.20 hose clamps Art. 3474 BN 12-20
No.20 hose clamps Art. 3474 BN 16-25
No.10 hose clamps Art. 3474 BN 20-32.
Complete set.
3474PA
Each 55,20
vuoto
BAND,HOSECLAMPS
3474PE
Assorted sets of No. 50 hose clamps Art. 3474 CN, in practical case Art. 2083 T 12.
Composition:
17 hose clamps Art. 3474 CN 16-27
5 hose clamps Art. 3474 CN 20-32
5 hose clamps Art. 3474 CN 25-40
10 hose clamps Art. 3474 CN 32-50
10 hose clamps Art. 3474 CN 40-60
3 hose clamps Art. 3474 CN 50-70.
Complete set.
3474PE
Each 52,16
