STAR REDUCERS FOR ARGON AND CARBON DIOXIDE
10
STAR REDUCERS FOR ARGON AND CARBON DIOXIDE
3140GME
ARGON - CARBON DIOXIDE
Orig. Ewo - Art. 123.470
Reduced dimension model for installing in tight spaces.
Body moulded in solid brass. Precision pressure gauges. Plastic pressure control button and
additional gas flow adjustment.
Internal threading, right 21.8 mm x 14 threads per inch.
Threaded G 1/4 inch rubber door.
Pressure gauge input scale from 0 to 300/315 Atm.
Pressure gauge output scale from 0 to 32 l/min.
Maximum input pressure from the bottle 200 Atm.
3140GME
Each 96,20
Spare pressure gauges on request.
vuoto
STARREDUCERSFORARGONANDCARBONDIOXIDE
HYDROGEN PRESSURE REGULATORS
3140GP
HYDROGEN
Orig. Ewo - Art. 120.357
Type with excellent quality/price ratio.
Forged body with upper part made from solid brass and lower part made from die-cast zinc.
Precision pressure gauges. Pressure adjusting knob made from synthetic material. Additional gas
flow adjustment device.
Internally threaded left-hand connection, 20x14mm threads per inch.
Hose connection diameter 6mm.
Pressure range inlet from 0 to 300/315 Atm.
Pressure range outlet from 0 to 15/16 Atm.
Max working pressure 10 Atm.
3140GP
Each 108,00
For spare manometers see Art. 3140 GEB and 3140 GEC.
vuoto
HYDROGENPRESSUREREGULATORS
NYTROGEN PRESSURE REGULATORS
3140GR
NITROGEN
Orig. Ewo - Art. 120.354
Very high quality/price ratio.
Forged body made from solid brass. Precision pressure gauges. Pressure adjusting knob made
from synthetic material. Additional gas flow adjustment device.
Externally threaded right-hand connection, 21.8x14mm threads per inch.
Hose connection diameter 6mm.
Pressure range inlet from 0 to 300/315 Atm.
Pressure range outlet from 0 to 15/16 Atm.
Max working pressure 10 Atm.
3140GR
Each 108,00
For spare manometers see Art. 3140 GEB und 3140 GEC.
vuoto
NYTROGENPRESSUREREGULATORS
CARBON DIOXIDE PRESSURE REGULATORS
3140GT
CARBON DIOXIDE
Orig. Ewo - Art. 120.356
Type with excellent quality/price ratio.
Forged body with upper part made from solid brass and lower part made from die-cast zinc.
Precision pressure gauges. Pressure adjusting knob made from synthetic material. Additional gas
flow adjustment device.
Internally threaded right-hand connection, 21.8x14mm threads per inch.
Hose connection diameter 6mm.
Pressure range inlet from 0 to 300/315 Atm.
Pressure range outlet from 0 to 15/16 Atm.
Max working pressure 10 Atm.
3140GT
Each 108,00
For spare manometers see Ar+L145t. 3140 GEB and 3140 GEC.
vuoto
CARBONDIOXIDEPRESSUREREGULATORS
COMPRESSED AIR PRESSURE REGULATORS
3140GZ
COMPRESSED AIR
Orig. Ewo - Art. 120.353
Type with excellent quality/price ratio.
Forged body with upper part made from solid brass and lower part made from die-cast zinc.
Precision pressure gauges. Pressure adjusting knob made from synthetic material. Additional air
flow adjustment device.
Internally threaded right-hand 7/8" GAS connection.
Hose connection diameter 6mm.
Pressure range inlet from 0 to 300/315 Atm.
Pressure range outlet from 0 to 15/16 Atm.
Max working pressure 10 Atm.
3140GZ
Each 108,00
For spare manometers see Art. 3140 GEB and 3140 GEC.
vuoto
COMPRESSEDAIRPRESSUREREGULATORS
