506 / 1410
506
Prices in EURO - VAT not included
7
506
AIR SCREW DRIVERS
1729G 3
1/4 ,,
Prod. Pneutec - Art. UT 5964
Pistol grip with torque control.
Adjustable clutch. Reversible operation. 1/4" hex inserts drive. Light alloy construction with steel
working parts. Lightweighted and reduced dimensions to be very handy. Blast pipe at the grip
lower extremity.
Max torque
Nm 6
Air consumption
l/sec
2
No-load speed
rev/min 1800
Noise level
dB 87,1
Vibrations
m/s²
3,7
Air drive
inch
1/4
Weight
Kg
1,6
1729G 3
Each 262,00
For inserts see Art. 1994 GH to Z. Operating pressure: Atm 6,3.
vuoto
AIRSCREW DRIVERS
1729G 3F
1/4 ,,
Prod. Pneutec - Art. UT 8963
Pistol-grip type with step adjustment of the tightening force by means of the external locking ring
installed on the device front side.
Reversible operation. Quick coupling for 1/4" hex inserts drive. Light alloy construction, coating in
synthetic material and steel working parts. Lightweighted and reduced dimensions to be very
handy. Blast pipe at the grip lower extremity.
Torque
Nm 1 to 9
Air consumption
l/sec
1
No-load speed
rev/min 750
Noise level
dB
76
Vibrations
m/s²
< 2,5
Air drive
inch
1/4
Weight
Kg
0,9
1729G 3F
Each 450,00
For inserts see Art. 1994 GH to Z. Operating pressure: Atm 6,3.
vuoto
AIRSCREW DRIVERS
OILS FOR AIR TOOLS
1730G
Orig. Ewo - Art. 583
Special synthetic oil for compressed air lubricators of pneumatic tools. While protecting tools it
increases their lifetime and performances even in difficult conditions such as high/low
temperatures, dirt, etc. It is biological. It does not contain poisonous substances, easy to be
disposed of. Supplied in handy 1l bottles, transfer pipe included.
1730G
Each 16,90
Viscosity category VG 32 - ISO 3448 (Viscosity 40°C - 32 mm²/s).
vuoto
OILSFORAIRTOOLS
COMPRESSED AIR HOSES
1732
Prod. SCU
Coil type made from elastomeric PA 12, particularly flexible and elastic. Maximum pressure 15
atm. Supplied with 1/4" thread, male and female.
Ø 8x6mm.
Overall length
m
5
7.5
10
15
1732
Each 9,70 13,10 16,40 23,40
For connections, couplings and nipples see Art. 3477 E to 3485 GC.
vuoto
COMPRESSEDAIRHOSES
1732A
Product description as Art. 1732
Ø 10x8mm.
Overall length
m
7.5
10
15
1732A
Each 16,70 21,20 30,30
For connections, couplings and nipples see Art. 3477 E to 3485 GC.
vuoto
COMPRESSEDAIRHOSES
1733
Coil type made from elastomeric PA 12, particularly flexible and elastic. Working pressure 15 bar.
Supplied without connectors.
Ø 8x6mm.
Overall length
m
5
7.5
10
15
1733
Each 6,82 10,30 13,70 20,50
vuoto
COMPRESSEDAIRHOSES
1733 1
Product description as Art. 1733
Ø 10x8mm.
Overall length
m
7.5
10
15
1733 1
Each 13,70 18,20 27,30
vuoto
COMPRESSEDAIRHOSES
