50 / 1410
50
DIN 5254A STRAIGHT PLIERS FOR LOOSE RETAINING EXTERNAL RINGS DIN 471 - DIN 983
2
50
Prices in EURO - VAT not included
276GB
new
Orig. Gedore - Art. 8000 AE
Precision type. Body made of CHROME VANADIUM steel, INSERTED tips made of bearing steel,
highly wear resistant, TILTED version for a better grip of the rings. Large support surface for the
ring to reduce the twist. Adjustable hinge screw for high precision and smoother tracking.
Phosphated head and plastic-coated handles.
With INTERNAL opening spring.
Overall length
mm
144
145
183
230
332
For rings Ø by
mm 3 to 10 10 to 25 19 to 60 40 to 100 85 to 140
276GB
Each 23,50 22,20 23,50 29,10 46,80
vuoto
DIN 5254ASTRAIGHTPLIERSFOR LOOSERETAININGEXTERNALRINGSDIN 471 -DIN 983
276GF
276GL
276GN
Orig. Gedore - Art. 8000 A
For rings as per DIN 471 and DIN 983.
Interchangeable straight tips. Made of CHROME-VANADIUM STEEL. Hardened noses.
Ratchet with lock lever.
Enamelled black finish.
Art......................................
276GF
276GL
276GN
Overall length
mm 550
550
586
For rings Ø by
mm 85 to 140 122 to 300 252 to 400
tips Ø
mm 3,2
3.5
4.5
Weight
grams 1900
1900
1950
Each 124,00
124,00
124,00
vuoto
Spare tips for Art. 276 GF.
O276GF
Per pair
16,10
vuoto
Spare tips for Art. 276 GL
O276GL
Per pair
16,10
vuoto
Spare tips for Art. 276 GN
O276GN
Per pair
16,10
vuoto
DIN 5254ASTRAIGHTPLIERSFOR LOOSERETAININGEXTERNALRINGSDIN 471 -DIN 983
276GN 4
Orig. Gedore - Art. 8005 A
Patented type, with tips parallel movement.
Particularly suitable for high-resistant large rings.
Complete with 4 interchangeable tips, for holes with out-of- standard distance between center
lines. Ratchet with clamping lever. Black enamelled finish.
Total length 665mm., for rings Ø from 305mm to 500mm, hole distance between center lines from
18mm to 50mm, tips Ø 4,5/5,9mm, weight 3650gr.
Complete pliers
276GN 4
Each 484,00
vuoto
Spare tips for Art. 276 GN 4
Type
1A
O276GNA
Each 28,20
vuoto
Type
2A
O276GNB
Each 28,20
vuoto
Type
3A
O276GNC
Each 28,20
vuoto
Type
4A
O276GND
Each 28,20
vuoto
DIN 5254ASTRAIGHTPLIERSFOR LOOSERETAININGEXTERNALRINGSDIN 471 -DIN 983
DIN 5254B CURVED PLIERS FOR LOOSE RETAINING EXTERNAL RINGS DIN 471 - DIN 983
277
Prod. SCU
Made of chrome-vanadium steel. Hardened.
Burnished. Plastic-coated handles. Curved bits 90 °.
Overall length
mm
130
170
205
300
For rings Ø by
mm 10 to 25 19 to 60 40 to 100 85 to 165
277
Each 12,40 13,90 17,30 28,20
vuoto
DIN 5254BCURVEDPLIERSFOR LOOSERETAININGEXTERNALRINGSDIN 471 -DIN 983
277GA
Orig. Gedore - Art. 8000 A
Made of chrome-vanadium steel. Hardened noses, thin for hard to reach spaces
Wide hinge with perfectly parallel jaws.
Enamelled black head and plastic-coated handles. 90° curved tips.
Overall length
mm
129
130
165
210
310
For rings Ø by
mm 3 to 10 10 to 25 19 to 60 40 to 100 85 to 140
277GA
Each 21,40 20,30 22,20 25,10 44,50
vuoto
DIN 5254BCURVEDPLIERSFOR LOOSERETAININGEXTERNALRINGSDIN 471 -DIN 983
