REINFORCED CONCRETE DRILL BITS FOR PERCUSSION HAMMERS
REINFORCED CONCRETE DRILL BITS FOR PERCUSSION HAMMERS
1338GBR
Prod. SCU
Very strong HARD METAL tool bits, tightly welded for quick drilling - without breaking - of
reinforced-concrete rods up to a diameter of 10mm. To be used when the drill for walls meets the
iron reinforcements with risk of break. Not suitable for drilling walls, stones, rocks etc. With hole
for the ejection of rod parts jammed inside the drill. Threaded connection suitable for several kinds
of percussion hammers through Universal Ratio adaptor Art. 1338 GE - 1338 GK.
For bores Ø
mm
12
14
16
18
20
25
28
30
Useful length
mm 190 190 190 190 190 190 190 190
1338GBR
Each 147,00 147,00 177,00 190,00 194,00 221,00 226,00 239,00
From a diameter of 25 mm drill bits may be used on extensions Art. 1338 GP.
vuoto
REINFORCEDCONCRETEDRILLBITSFORPERCUSSIONHAMMERS
ROTARY CORE BITS FOR PERCUSSION HAMMERS
1338GC
Prod. SCU
Pilot drill bit, with HARD METAL tool bit.
Suitable for walls, concrete conglomerates, stones, rocks and reinforced concrete.
Interchangeable centering pilot drill tip.
Threaded shank suitable for several kinds of percussion hammers through Universal Ratio
adaptor Art. 1338 GE.
Core bit total length 105mm.
Core bit with pilot drill bit.
Nibbling machine crown Ø mm
40
50
65
80
90
100 125 150
1338GC
Each 127,10 141,10 154,10 180,10 192,10 218,10 283,10 348,10
vuoto
ROTARYCOREBITSFORPERCUSSIONHAMMERS
1338GCA
Product description as Art. 1338GC
Core bit without pilot drill bit.
Nibbling machine crown Ø mm
40
50
65
80
90
100 125 150
1338GCA
Each 103,00 117,00 130,00 156,00 168,00 194,00 259,00 324,00
vuoto
ROTARYCOREBITSFORPERCUSSIONHAMMERS
1338GCB
Pilot drill bit, with HARD METAL tool bit.
Ø
mm 12
Length
mm 155
1338GCB
Each 24,10
For extensions see Art. 1338 GP.
vuoto
ROTARYCOREBITSFORPERCUSSIONHAMMERS
NIBBLING HEADS FOR PERCUSSION HAMMERS
1338GDA
Prod. SCU
Pilot drill bit, with HARD METAL inserts.
Excellent performance with little effort. A new drilling technique to obtain deep holes with a large
diameter in several kinds of materials such as concrete conglomerates, walls, stones, rocks,
marbles, granites, Klinker and reinforced concrete. With threaded bore for pilot drill bit, discharge
spiral bit and Universal Ration adaptor Art. 1338 GE.
Head without pilot drill tip.
Nibbling machine head Ø mm
35
42
52
65
80
90
100
1338GDA
Each 140,00 164,00 210,00 288,00 309,00 342,00 399,00
Nibbling machine head Ø mm
110
125
150
1338GDA
Each 399,00 576,00 821,00
vuoto
NIBBLINGHEADSFORPERCUSSIONHAMMERS
1338GDE
DISCHARGE SPIRAL BITS FOR HEADS ART. 1338 GDA
Made of forged and ground steel, with Ratio adaptor.
. Trapezoidal strengthened twist drill for very high material removal rate. Working length 80mm.
Total length 115mm.
Spiral bit without pilot drill tip.
spiral Ø
mm
32
47
63
78
For nibbling heads Ø mm 35 and
42
52 and
65
65 and
80
80 to
150
1338GDE
Each 56,80 80,80 107,00 128,00
vuoto
Interchangeable threaded screw starting from size with diameter 30mm. Suitable for Art. 1338
GDE.
OB1338GDE
Each 15,10
vuoto
NIBBLINGHEADSFORPERCUSSIONHAMMERS
