124 / 1410
124
ELECTRICAL CABLE CUTTERS WITH RATCHET
2
124
Prices in EURO - VAT not included
617GPA
Orig. Baudat - Art. 80-067 (Mod. SCZ 55)
Rack-type with ratchet mechanism. Closed blade cut.
Extra-high resistance CHROME-VANADIUM steel head, long arms made of shaped tubular steel
and ergonomic grips.
With pull-back spring. Easy and progressive cutting.
Suitable for cutting copper and aluminium cables (not suitable for fine wires or reinforced steel
cables and aluminium alloys).
Overall length
mm 430
For copper and aluminium cables up to Ø mm 55
Weight
Kg
1,6
617GPA
Each 397,00
Spare knives supplied on request.
vuoto
ELECTRICALCABLECUTTERSWITHRATCHET
617GQ
Orig. Baudat - Art. 80-912 (Mod. HCF75)
Rack-type with ratchet mechanism. Long straight blades to cut flat cables without deformation.
Extra-high resistance CHROME-VANADIUM steel head, arms made of shaped tubular steel and
ergonomic grips.
For flat copper and aluminium cables. Width: 75mm
Overall length
mm 525
Drive ratio
1:60
Weight
Kg
1,7
617GQ
Each 523,00
Shears for ribbon cables, see Art. 709 GS.
vuoto
Spare blade rack type for Art. 617 GQ.
O617GQ 1
Each 263,00
vuoto
Spare blade without rack for Art. 617 GQ.
O617GQ 2
Each 269,00
vuoto
ELECTRICALCABLECUTTERSWITHRATCHET
ELECTRICAL CABLE CUTTERS WITH RATCHET MECHANISM
617GR
Orig. Baudat - Art. 80-051 (Mod. SR52)
Stationary model, with ratchet.
High-resistance steel body.
Forged blades.
Operating lever with ergonomically designed handle.
Ideal for use in workshop or to cut cables in coils.
High cutting performances with small effort of power required.
For copper and aluminium cables up to Ø mm 52
For copper and aluminium cables max. sect. mm²
450
Weight
Kg
8,3
617GR
Each 968,00
vuoto
Spare blade rack type for Art. 617 GR.
O617GR 1
Each 186,00
vuoto
Spare blade without rack for Art. 617 GR.
O617GR 2
Each 161,00
vuoto
ELECTRICALCABLECUTTERSWITHRATCHETMECHANISM
OIL-HYDRAULIC CABLE CUTTERS FOR ELECTRICAL CABLES
617GS
Orig. Baudat - Art. 60-153 (Mod. HS3D)
Hydraulic-operated leveraged model.
Special steel body, forged head.
Easy cut, high cutting power for copper and aluminium cables.
Sturdy and easy to handle.
Clamping force approx. 35KN at 500 BAR.
Overall length
mm 600
For copper and aluminium cables up to Ø mm 50
For copper and aluminium cables max. sect. mm²
450
Weight
Kg
5,6
617GS
Each 3.080,00
vuoto
Spare blades for Art. 617 GS - 617 GSA.
O617GS
Per pair
562,00
vuoto
OIL-HYDRAULICCABLECUTTERSFORELECTRICALCABLES
HAND-OPERATED CUTTERS FOR STEEL WIRE ROPES
618GM
Prod. SCU
High resistance steel head. Body in heavy steel sheet.
Opening spring. Plastic coated handles. Suitable for cutting steel wire ropes.
Blades with triangular cutting edges increase cutting capacity and assure quick and precise cuts
without deformations.
Suited to steel wire ropes up to Ø 3mm and copper wire up to Ø 6mm.
Overall length
mm 190
618GM
Each 21,40
vuoto
HAND-OPERATEDCUTTERSFORSTEELWIREROPES
