1087 / 1410
1087
Prices in EURO - VAT not included
1087
DIAMOND GRINDING POINTS
12
DIAMOND GRINDING POINTS
7884GP
Prod. SCU
Special type with diamond surface, long duration and high performance.
Particularly indicated for working hard metal, hardened steel, glass, ceramics, etc.
Revolving speed up to 20 m/sec.
Medium grit (B 126).
Cylindrical shape.
Size
1
2
3
4
5
6
7
8
Head Ø and height
mm 2x5 3x5 4x6 5x6 6x6 1x3 1,5x3 2x5
Drive Ø
mm 2,35 2,35 2,35 2,35 2,35
3
3
3
Overall length
mm 40
40
40
40
40
40
40
40
7884GP
Each 13,10 13,10 13,10 13,10 13,10 13,10 13,10 13,10
Size
9
10
11
12
13
14
15
Head Ø and height
mm 2,5x5 3x5 4x5 5x6 6x7 8x10 10x10
Drive Ø
mm 3
3
3
3
3
6
6
Overall length
mm 40
40
40
40
40
60
60
7884GP
Each 13,10 13,10 13,10 13,10 13,10 24,90 33,10
vuoto
DIAMONDGRINDINGPOINTS
7884GS
Product description as Art. 7884GP
Sphere shape.
Size
1
2
3
4
5
6
7
Head Ø
mm 2
3
4
5
2
3
4
Drive Ø
mm 2,35
2,35
2,35
2,35
3
3
3
Overall length
mm 40
40
40
40
40
40
40
7884GS
Each 13,10 13,10 13,10 13,10 12,50 12,50 12,50
Size
8
9
10
11
12
Head Ø
mm 5
6
8
10
12
Drive Ø
mm 3
3
6
6
6
Overall length
mm 40
40
60
60
60
7884GS
Each 12,50 12,50 31,90 36,10 50,40
vuoto
DIAMONDGRINDINGPOINTS
7884GT
Special type with diamond surface, long duration and high performance.
Particularly indicated for working hard metal, hardened steel, glass, ceramics, etc.
Revolving speed up to 20 m/sec. Medium grit (D 126).
Cylindrical round nose.
Size
1
2
3
4
5
6
7
Head Ø and height
mm 3x15 4x10 5x10 6x10 8x10 10x10 6x20
Drive Ø
mm 3
3
3
3
3
3
6
Overall length
mm 40
40
40
40
40
40
60
7884GT
Each 14,70 15,20 15,90 18,70 26,60 34,50 19,60
Size
8
9
10
11
12
13
14
Head Ø and height
mm 8x15 10x15 12x15 14x15 16x15 18x15 20x15
Drive Ø
mm 6
6
6
6
6
6
6
Overall length
mm 60
60
60
60
60
60
60
7884GT
Each 26,60 34,50 39,30 43,50 47,20 49,30 51,30
vuoto
DIAMONDGRINDINGPOINTS
7884GV
Product description as Art. 7884GT
Cylindrical pointed nose.
Size
1
2
3
4
5
6
Head Ø and height
mm 4x8
5x10 6x10 7x12 8x13 10x15
Drive Ø
mm 3
3
3
3
3
3
Overall length
mm 40
40
40
40
40
40
7884GV
Each 24,90 27,50 29,60 35,60 40,40 44,40
vuoto
DIAMONDGRINDINGPOINTS
7884GZ
Product description as Art. 7884GT
Conical shape - 60° top angle.
Size
1
2
3
4
5
6
Head Ø and height
mm 3x2,60 4x3,46 5x4,33 6x5,20 8x6,93 10x8,66
Drive Ø
mm 3
3
3
3
6
6
Overall length
mm 42,60
43,46
44,33
45,20
66,93
68,66
7884GZ
Each 13,10
15,10
15,10
15,10
28,10
35,60
Size
7
8
9
10
11
12
Head Ø and height
mm 12x10,40 14x12,12 15x12,99 16x13,86 18x15,59 20x17,32
Drive Ø
mm 6
6
6
6
6
6
Overall length
mm 70,40
72,12
72,99
73,86
75,59
77,32
7884GZ
Each 41,10
43,20
48,60
50,60
52,50
56,20
vuoto
DIAMONDGRINDINGPOINTS
