HAND RIVETERS
2
102
Prices in EURO - VAT not included
500
Long lever type for limited effort and use in difficult to access areas.
In cast aluminium body, sturdy sheet steel levers,
synthetic material ergonomic handles. With 5 heads.
With plastic tray to collect cut-down ends.
For aluminium, copper, steel, stainless steel rivets up to Ø mm. 6,4.
Overall length
mm 530
Weight
Kg 1,810
500
Each 80,10
vuoto
HANDRIVETERS
501
With a single rotating head for rivets of four measures: 3.2-4-4.8/5-6.4 mm. Advantages: there is
no need to replace the heads depending on the measurement of the rivet and this prevents the
heads from getting lost.
With long levers for limited effort and for use in places that are hard to reach. Aluminium cast body
and steel lever. Ergonomic handles made of rubbery material.
With plastic container to collect fragments.
For aluminium, copper, steel, stainless steel rivets up to Ø 6.4 mm.
Overall length
mm 400
Weight
Kg 2,000
501
Each 66,40
vuoto
HANDRIVETERS
502A
Pantograph type for one-hand use.
Die-cast aluminium head and handle. With four heads.
Max extension 320 to 850mm.
For aluminium, copper, steel, stainless steel rivets up to Ø mm. 6,4.
Weight
Kg 1,660
502A
Each 139,00
vuoto
HANDRIVETERS
AIR RIVETERS
504G
Prod. Pneutec - Art. UT4DPP
Oleo-pneumatic type, light and handy for maintenance works.
Light alloy body, steel operating parts.
Air attachment R 1/4. Use pressure 6,3 Atm. With plastic tray to collect cut-down ends.
Only for aluminium and copper rivets up to Ø mm. 4,8
Length
mm 260
Air consumption
l/sec 1,2
Noise level
dB 77,5
Vibrations
m/sec² < 2,5
Weight
Kg 1,500
504G
Each 255,00
vuoto
AIRRIVETERS
504GC
Prod. SCU
Oleo-pneumatic type, light and easy to handle for maintenance work.
Light alloy body, steel operating parts, handle made from insulating material.
1/4" GAS female air connection (for standard snap-on coupling see Art. 3478 D 1/4). Working
pressure 6.5 Atm. With rivet retainer and plastic tank for collection of small waste part.
For aluminium rivets up to Ø 4.8mm.
For copper, steel, STAINLESS steel rivets up to Ø 4mm.
Length
mm 300
Weight
Kg 1,450
504GC
Each 570,00
vuoto
AIRRIVETERS
504GE
Prod. Pneutec - Art. UT6DPP
Oleo-pneumatic type, strong and long-lasting. Light alloy body, steel operating parts.
R 1/4 air connection. Operating pressure 6.3 Atm.
With plastic tank for the collection of small waste parts.
For rivets (copper and aluminium only) up to Ø 6.4mm.
Length
mm 310
Air consumption
l/sec 1,7
Noise level
dB 77
Vibrations
m/sec²
4,8
Weight
Kg 2,100
504GE
Each 752,00
vuoto
