947
DIAL TEST INDICATORS, SWIVEL CONTACT POINT
947
11
Prices in EURO - VAT not included
DIAL TEST INDICATORS, SWIVEL CONTACT POINT
4412GC
1/100
Prod. SCU - Orig. Käfer
Dial Ø 28mm, stem Ø 8mm x h 6, 1/100 graduations.
Travel 0.8mm, for tolerance ±0.4mm right-left with lateral movement.
Swivel range of contact point 220°. To be mounted on articulated holder Art. 4412 GS.
Rod with contact point, length 12.3mm.
4412GC
Each 166,00
vuoto
DIALTEST INDICATORS,SWIVELCONTACTPOINT
4412GF
1/100
High precision model, with dial Ø 40mm, 1/100 graduations.
Stem Ø 4 or 8mm x h 6, inserted from above, travel 0.8mm, for tolerance ±0.4mm forward-
backward with front movement.
Swivel range of stylus in hard metal 240°.
To be mounted on articulated holder Art. 4412 GS and arch centering Art. 4412 GT by joint Art.
O4412 GM 4 or 8.
Rod with contact point, length 12mm.
4412GF
Each 167,00
vuoto
DIALTEST INDICATORS,SWIVELCONTACTPOINT
4412GL
1/100
High precision model, with dial Ø 40mm, 1/100 graduations.
Stem Ø 4 or 8mm x h 6, inserted from above, travel 0.5mm, for tolerance ±0.25mm forward-
backward with front movement.
Swivel range of stylus in hard metal 240°.
To be mounted on articulated holder Art. 4412 GS and arch centering Art. 4412 GT by joint Art.
O4412 GM 4 or 8.
Extended rod with contact point, length 35mm.
4412GL
Each 231,00
vuoto
DIALTEST INDICATORS,SWIVELCONTACTPOINT
4412GM
2/1000
Very high precision model, with dial Ø 40mm, 2/1000 graduations.
Stem Ø 8mm x h 6, inserted from above, travel 0.2mm, for tolerance ±0,1 mm forward-backward
with front movement.
Swivel range of stylus in hard metal 240°.
To be mounted on articulated holder Art. 4412 GS and arch centering Art. 4412 GT by joint Art.
O4412 GM 4 or 8.
Rod with contact point, length 12mm.
4412GM
Each 201,00
vuoto
Stem fittings Ø 4 mm, inserted in the head, on comparators Art. 4412 GF - L - M.
O4412GM 4
Each 17,40
vuoto
Stem fittings Ø 8 mm, inserted in the head, on comparators Art. 4412 GF - L - M.
O4412GM 8
Each 17,40
vuoto
DIALTEST INDICATORS,SWIVELCONTACTPOINT
4412GS
Articulated support for comparators with hole for attacks Ø mm 4 e 8.
Dimensions 80x12x6mm.
4412GS
Each 27,30
vuoto
DIALTEST INDICATORS,SWIVELCONTACTPOINT
4412GT
new
Centering arches with connection pin Ø 8 mm and holes for attacks comparators Ø 4 and 8 mm.
4412GT
Each 59,20
vuoto
