PUNCHING PLIERS
92
2
Prices in EURO - VAT not included
430G 2
Product description as Art. 430G 1
Reinforced type. Front head.
With punch Ø 5mm.
Overall length
mm 260
Max span
mm 30
For sheets with max. thickness mm 1.5
For bores by
mm 2 to 5
430G 2
Each 73,60
For spare punches and dies see Art. 432 G.
PUNCHINGPLIERS
430G 4
Product description as Art. 430G 1
With return spring, head suitable for punching angular bodies.
With spacer.
With punch Ø 6mm.
Overall length
mm 300
Max span
mm 40
For sheets with max. thickness mm 1.25
For bores by
mm 4 to 6
430G 4
Each 110,00
For spare punches and dies see Art. 432 GM.
PUNCHINGPLIERS
430G 5
Product description as Art. 430G 1
Pliers type.
With puncher Ø 8mm.
Overall length
mm 315
Max span
mm 40
For sheets with max. thickness mm 1.75
For bores by
mm 2 to 8
430G 5
Each 110,00
For spare punches and dies see Art. 432 GS.
PUNCHINGPLIERS
430G 8
Product description as Art. 430G 1
Pliers type.
Reinforced details.
High-resistance steel punches. Weight 4,5Kg.
With punch Ø 10mm.
Overall length
mm 520
Max span
mm 40
For sheets with max. thickness mm 1.5
For bores by
mm 3 to 10
430G 8
Each 596,00
For spare punches and dies see Art. 432 GV.
PUNCHINGPLIERS
RATCHET PUNCHING PLIERS
430GA
Orig. Baudat - Art. 80-802. (Mod. LZ 2000)
Special type with ratchet movement for powerful punching action (200KN).
Limited load, die and punch integrated in one single interchangeable support for rapid adjustment.
Special steel head and plastic ergonomic handles with hand protector.
Weight 1,3Kg.
Without die/punch support.
Overall length
mm 280
Max span
mm
50
For sheets with max. thickness mm
2
For round bores by
mm 4 to 13
For rectangular bores by
mm 5x10 to 7x13
430GA
Each 546,00
vuoto
RATCHETPUNCHINGPLIERS
430GB
Orig. Baudat
DIES SUPPORTS COMPLETE WITH ROUND PUNCHES FOR ART. 430 GA
Die support with punch.
Ø
mm
4,2
5
6
7
9
10,5 11
13
430GB
Each 263,00 263,00 263,00 150,00 150,00 150,00 150,00 150,00
vuoto
RATCHETPUNCHINGPLIERS
430GE
DIES SUPPORTS COMPLETE WITH RECTANGULAR PUNCHES FOR ART. 430 GA
Die support with punch.
Dimensions
mm
5x10 5x13 6x13 7x13
430GE
Each 882,00 560,00 560,00 560,00
vuoto
RATCHETPUNCHINGPLIERS
