738
PROPAN PRESSURE REGULATORS
738
10
Prices in EURO - VAT not included
PROPAN PRESSURE REGULATORS
3140GF
LIQUEFACTED GAS
Orig. Ewo - Art. 120.352
Type with excellent quality/price ratio.
Forged body with upper part made from solid brass and lower part made from die-cast zinc.
Precision pressure gauges. Pressure adjusting knob made from synthetic material. Additional gas
flow adjustment device.
Internally threaded left-hand connection, 20x14mm threads per inch.
Threaded hose connection G 3/8 left-hand.
Hose connection diameter 6mm.
Suitable for liquid gases such as propane and butane.
Pressure range outlet from 0 to 6 Atm.
Max working pressure 3.5 Atm.
3140GF
Each 99,30
vuoto
PROPANPRESSUREREGULATORS
3140GFA
Orig. Ewo
SPARE MANOMETERS
Pressure range from 0 to 6 Atm.
3140GFA
Each 16,80
vuoto
PROPANPRESSUREREGULATORS
ARGON - CARBON DIOXIDE REDUCERS
3140GL
ARGON - CARBON DIOXIDE
Orig. Ewo - Art. 120.470
Very high quality/price ratio.
Forged body made from solid brass. Precision pressure gauges. Pressure adjusting knob made
from synthetic material. Additional gas flow adjustment device.
Internally threaded right-hand connection, 21.8x14mm threads per inch.
Threaded hose connection G 1/4.
Hose connection diameter 6mm.
Pressure range inlet from 0 to 300/315 Atm.
Pressure range outlet from 0 to 32 l/min.
Cylinder max. inlet pressure: 200 Atm.
3140GL
Each 92,60
vuoto
SPARE MANOMETERS
Manometers for flow measurement.
O3140GL
Each 16,80
vuoto
Manometers for pressures from 0 to 300/315 Atm see Art. 3140 GEB.
ARGON -CARBONDIOXIDEREDUCERS
ARGON - CARBON DIOXIDE REDUCERS WITH FLOW METER
3140GM
ARGON - CARBON DIOXIDE
Orig. Ewo - Art. 120.472
Type with excellent quality/price ratio.
Forged body with upper part made from solid brass and lower part made from die-cast zinc.
Internally threaded right-hand connection, 21.8x14mm threads per inch.
Hose connection diameter 6mm.
Pressure range inlet from 0 to 300/315 Atm and graduated adjustable flowmeter 0-20 l/min. for
gas flow regulation
3140GM
Each 172,00
For spare manometers see Art. 3140 GEB.
Spare flowmeters available on request.
vuoto
ARGON -CARBONDIOXIDEREDUCERSWITH FLOWMETER
STAR REDUCERS FOR ARGON AND CARBON DIOXIDE
3140GME
ARGON - CARBON DIOXIDE
Orig. Ewo - Art. 123.470
Reduced dimension model for installing in tight spaces.
Body moulded in solid brass. Precision pressure gauges. Plastic pressure control button and
additional gas flow adjustment.
Internal threading, right 21.8 mm x 14 threads per inch.
Threaded G 1/4 inch rubber door.
Pressure gauge input scale from 0 to 300/315 Atm.
Pressure gauge output scale from 0 to 32 l/min.
Maximum input pressure from the bottle 200 Atm.
3140GME
Each 90,10
Spare pressure gauges on request.
vuoto
STARREDUCERSFORARGONANDCARBONDIOXIDE
