37 / 1378
37
CRIMPING PLIERS FOR NON-INSULATED TERMINALS
37
2
Prices in EURO - VAT not included
206GH 1
Product description as Art. 206GE
Cable lugs for cables by mm
2
8 to 38
Overall length
mm 330
206GH 1
Each 155,00
vuoto
CRIMPINGPLIERSFORNON-INSULATEDTERMINALS
206GH 50
Prod. SCU
Double-lever type for effort reduction.
In pressed steel. Steel pipe handles with soft synthetic material coated handles.
The rotating disk can be positioned on the desidered value, in hardened special steel. For non-
insulated terminals and junctions.
Cable lugs for cables by mm
2
6-10-16-25-35-50
Overall length
mm
600
Weight
Kg
2,4
206GH 50
Each
336,00
vuoto
CRIMPINGPLIERSFORNON-INSULATEDTERMINALS
206GK
Double-lever type for effort reduction. In pressed steel. Steel pipe handles and detachable
extensions with soft synthetic material coated handles.
The rotating disk can be positioned on the desidered value, in hardened special steel. For non-
insulated terminals and junctions.
Cable lugs for cables by mm
2
50-70-95-120
Overall length
mm 970
Weight
Kg
4,400
206GK
Each 343,00
Similar products with capacity from 120 to 240 sqmm are available on request.
vuoto
HYDRAULIC PLIERS FOR NON-INSULATED TERMINALS AND "C" CONNECTORS
206GK 9
Prod. SCU
High-performance professional type for non-insulated terminals and “C" connectors. Hydraulic
lever operated.
180° revolving head. Max pressure 50 KN. In high-resistance steel, burnished, with rubber
handle. Pliers length 360mm.
The set contains: 1 hydraulic pliers, 5 couples of dies for non-insulated terminals
from 10 to 150 sqmm and 2 couples of dies for "C" connectors from 16 to 35 sqmm.
Pliers weight: kg 2.
In case.
206GK 9
Each 2.260,00
Couples of spare and additional dies are available on request.
vuoto
CRIMPING PLIERS FOR NON-INSULATED OPEN TERMINALS
207G
Orig. Marvel
In special steel. Combined with threaded screw cutters, wire strippers and cable cutters with
lapped cutting edges additionally induction hardened. Plastic-coated handles. Thickness 3,2mm.
Joint pin amply dimensioned and hardened.
Cable lugs for cables by
mm
2
1.5 to 6
Bolt cutters by
M 2.6 to M 5
Stripper for cables by
mm
2
0.75 to 6
Wire cutter by
mm
2
0.5 to 6
Overall length
mm 220
207G
Each
18,60
vuoto
CRIMPINGPLIERSFORNON-INSULATEDOPENTERMINALS
207G 8
Prod. SCU
Professional heavy type, mod. ZENITH C60 made from special steel. Working parts are hardened
and finely tuned.
Combined with threaded cutters, wire strippers and cutters with edges which have been further
hardened through induction. Handle with plastic coating. 4 mm thick. Generously sized hinge pin,
tempered, and finely tuned.
Cable lugs for cables by mm²
0 to 8
Bolt cutters by
M 2,5 to M 5
Wire cutter by inches
W 3/32 to W 3/16
Stripper for cables by
mm²
2 to 8
Wire cutter by
mm²
0,5 to 8
Overall length
mm
215
207G 8
Each
47,70
vuoto
CRIMPINGPLIERSFORNON-INSULATEDOPENTERMINALS
