174 / 1378
174
HYDRAULIC PIPE BENDERS
174
2
Prices in EURO - VAT not included
785M
DIES FOR HYDRAULIC TUBING BENDERS ART. 784 Z – 785 A-B-C-D-E.
For pipes Ø
inches
3/8
1/2
3/4
1
1.1/4 1.1/2
2
2.1/2
Bending radius
mm 45
55
70
95
135 155 200 320
785M
Each 52,90 59,90 77,50 103,00 134,00 177,00 282,00 493,00
For pipes Ø
inches
3
3.1/2
4
Bending radius
mm 350 540 600
785M
Each 634,00 272,00 335,00
For pipes Ø
mm
10
12
14
16
18
20
22
24
Bending radius
mm 35
35
40
45
45
55
55
55
785M
Each 56,40 59,90 63,40 66,90 70,50 70,50 95,10 103,00
For pipes Ø
mm
26
28
30
32
35
38
40
Bending radius
mm 70
70
70
90
95
95
130
785M
Each 110,00 124,00 131,00 138,00 152,00 169,00 180,00
vuoto
HYDRAULICPIPEBENDERS
785TG
Device used for bending and straightening DIN 2440 pipes. For right or left bends.
For cold bending of empty gas pipes up to 90°.
Very powerful pump. Equipped with 3 support legs and 1 control lever with handle.
With no. 6 dies for pipes ranging from 1/4-3/8-1/2-3/4-1-1.1/4-1.1/2-2. (Only one die is used for
bending Ø 1/4-3/8 and 1/2).
Complete in case.
785TG
Each 1.600,00
vuoto
HYDRAULICPIPEBENDERS
785VG
SPARE DIES FOR ART. 785 TG.
For pipes Ø
inches
3/8-1/2
3/4
1
1.1/4
1.1/2
2
Bending radius
mm 63
78
98
128
148
202
785VG
Each 18,40
26,50
44,80
118,00 118,00 168,00
The die for pipes from 3/8 -1/2 inches is also used for bending pipes from ¼ inches.
vuoto
HYDRAULICPIPEBENDERS
786A
786B
Orig. Gedore - Art. 246010
Pipe bender. For right or left bends.
For cold bending of the following empty pipes up to 180°: stainless steel pipes up to Ø 22mm,
max. thickness 1.5mm, soft and annealed copper pipes DIN EN 1057 up to Ø 28mm, hydraulic
pipes and mild steel pipes up to Ø 28mm, max. thickness 2mm, gas and water pipes DIN 2440 Ø
3/8-1/2-3/4.
Sturdy body and very powerful pump (60 kN).
Equipped with 3 support legs and 1 control lever with handle.
In transport case.
Without dies.
786A
Each 4.520,00
vuoto
Orig. Gedore - Art. 246100
Product description as Art. 786A
The set contains a pipe bender Art. 786 A and 5 dies Art. 786 E 12-15-18-22-28mm.
786B
Each 6.210,00
vuoto
HYDRAULICPIPEBENDERS
786E
Orig. Gedore - Art. E 246
DIES PROVIDED WITH GUIDE ART. 786 A-B TO BEND HYDRAULIC PIPES.
For pipes Ø
mm
6
8
10
12
14
15
16
Bending radius
mm 35
35
45
45
55
55
75
786E
Each 254,00 254,00 254,00 254,00 282,00 282,00 333,00
For pipes Ø
mm
18
20
22
25
28
Bending radius
mm 75
75
85
85
112
786E
Each 333,00 333,00 363,00 363,00 396,00
Dies to bend pipes Ø 3/8-1/2-3/4 available on request.
vuoto
HYDRAULICPIPEBENDERS
