1276
TURNING OFF TOOL HOLDERS
1276
13
Prices in EURO - VAT not included
TURNING OFF TOOL HOLDERS
9716G
Orig. Hufnagel
Treated steel body.
Safe locking system.
HSS-E bars, trapezoidal section, hardened and ground.
"Orkan-S" quality (W 12% - Co 5% - Va 4%).
Tool holder with bar.
Size Da
1
2
3
Bar dimensions
mm 80x8x2 100x10x2,5 125x15x3,5
Height from base to cutting edge mm 12
14
22
Blades holder overall length
mm 125
140
160
Blades sections
mm 17x12
22x15
30x17
9716G
Each 147,00
161,00
244,00
Product running out of stock.
vuoto
TURNINGOFFTOOLHOLDERS
9717G
HSS
“Orkan-S" bars, hardness HRC 66. For Art. 9716 G.
Size Da
1
2
4
Bar dimensions
mm 80x8x2 100x10x2,5 150x19x4,5
9717G
Each 32,60
37,50
76,00
Product running out of stock.
vuoto
TURNINGOFFTOOLHOLDERS
TOOL HOLDERS AND BARS FOR INSIDE USE
9720G
Orig. Hufnagel
Tool holder.
Treated steel, for bars Art. 9721 G to 9725 G.
Without bar.
Overall length
mm
120
For bars Gr.
BN 5-7-10-13-16
Section
mm 16x16
Cut height
mm
8
9720G
Each
85,10
Product running out of stock.
vuoto
TOOLHOLDERSANDBARSFOR INSIDEUSE
9721G
HSS-E
Bars for Art. 9720 G.
HSS-E Cobalt 10%, “Orkan-S" quality
(W 9% - Co 10% - Mo 3.5). Hardness HRC 65-67.
Particularly used on universal milling machines, revolver and automatic lathes.
Once the head is worn out, they may be used as normal round bars.
Bars for roughing
Size BN
5
10
16
Overall length
mm 60
65
100
Drive length
mm 35
45
78
Drive Ø
mm 8
8
10
For bore by Ø min
mm 5
10
16
9721G
Each 48,70 56,60 93,50
Product running out of stock.
vuoto
TOOLHOLDERSANDBARSFOR INSIDEUSE
9722G
HSS-E
Product description as Art. 9721G
Bars for finishing.
Size BN
13
16
Overall length
mm 75
100
Drive length
mm 52
78
Drive Ø
mm 10
10
For bore by Ø min
mm 13
16
9722G
Each 68,90 93,50
Product running out of stock.
vuoto
TOOLHOLDERSANDBARSFOR INSIDEUSE
9724G
60
HSS-E
Product description as Art. 9721G
Bars for 60° Metric thread.
Size BN
13
16
Overall length
mm 75
100
Drive length
mm 42
78
Drive Ø
mm 10
10
For bore by Ø min
mm 13
16
9724G
Each 73,30 98,20
Product running out of stock.
vuoto
