121
COMPOUND ACTION CUTTERS
121
2
Prices in EURO - VAT not included
585G
Type with front cutting edges for wires up to R 2000 N/sqmm.
Made from forged steel. Cutting edges additionally hardened.
Varnished handles. DIN ISO 5748.
Overall length
mm
180
210
235
For hard wires up to Ø mm 3,7
4,2
4,7
For harmonic wire up to Ø mm 2
2,2
2,5
585G
Each 60,50 61,90 67,40
vuoto
COMPOUNDACTIONCUTTERS
593G
Type with side cutting edges for wires up to R 2000 N/sqmm.
Made from forged steel. Cutting edges additionally hardened.
Varnished handles. DIN ISO 5749.
Overall length
mm
195
225
For hard wires up to Ø mm 3
4,7
For harmonic wire up to Ø mm 1,8
2,5
593G
Each 60,50 69,10
vuoto
COMPOUNDACTIONCUTTERS
595GA
595GB
Orig. Gedore - Art. 8340 Z - 200 TL
Power cutting model.
Made from CHROME-VANADIUM, fully hardened by oil, with additional hardening induction on
the cutting edges. The specific shape of the head and the position of the hinge create a
favourable lever ratio which allows the power to be reduced by approximately 60% when
compared to a cutter of equal length.
For use with piano wire, hard wire, soft wire, and rods, bolts, nails, screws, rivets, etc.
Total length of 200 mm.
Can cut piano wire with a diameter of up to 3.8 mm.
Can cut hard wire with a diameter of up to 5.5 mm.
Can cut soft wires and rods up with a diameter of up to 6 mm.
With plastic coated handles.
595GA
Each 56,70
vuoto
Orig. Gedore - Art. 8340 Z - 200 JL
Product description as Art. 595GA
With handles in bi-component material.
595GB
Each 60,10
vuoto
COMPOUNDACTIONCUTTERS
CUTTERS AND BOLT CUTTERS
599G
Prod. SCU
Double fulcrum type.
Blades in alloyed hardened steel.
Steel sheet handles with adjusting screw, covered with synthetic material, with spring.
Straight side cutting edge type.
Suited to hard steel wire and piano wire.
Overall length
mm 200
For hard wires up to Ø mm 3
For harmonic wire up to Ø mm 2,5
599G
Each 41,30
vuoto
CUTTERSANDBOLTCUTTERS
599GB
Product description as Art. 599G
Frontal cutting edge type.
Suited to hard steel wire.
Overall length
mm 200
For hard wires up to Ø mm 2
599GB
Each 41,30
vuoto
CUTTERSANDBOLTCUTTERS
BOLT CUTTERS
602E
Prod. SCU
Model for cuts up to R 1330 N/sqmm (HRC 40).
High-resistance steel blades.
Tubular steel handles with rubber grips.
Overall length
mm
350
450
600
750
900
For cutting R500 N/mm² up to Ø mm 6
8
9
11
13
For cutting R500 N/mm² up to Ø mm 5
6
8
9
10
602E
Each 28,40 32,90 43,40 69,10 89,70
vuoto
Spare heads for Art. 602E.
For iron cutters length
mm
350
450
600
750
900
O602E
Each 19,10 22,60 30,30 44,20 60,10
vuoto
BOLTCUTTERS
