1044
UNIVERSAL STEEL BAR CLAMPS
1044
12
Prices in EURO - VAT not included
5245GME
Orig. Kanca
In forged and hardened steel, profiled bar.
Quick adjusting tightening device with clamp and mobile interchangeable clamping surface.
Tested at very high clamping pressure.
Totally galvanized, burnished clamp screws.
Sliding grip.
Reinforced model.
Throat 140mm. Bar cross section 30x15mm. Reachable pressure with 150mm opening: approx.
15000 N (1500 Kg) equivalent to 50 Nm torque value.
Useful opening
mm
200
250
300
400
500
600
800
Weight
Kg
2,5
2,8
3
3,4
3,7
4,1
4,7
5245GME
Each 46,10 48,10 50,20 54,30 58,70 62,80 71,40
Useful opening
mm
1000 1200
Weight
Kg
5,2
5,7
5245GME
Each 79,50 83,80
vuoto
UNIVERSALSTEELBARCLAMPS
5245GP
Prod. SCU
In forged and hardened steel, profiled bar.Quick adjusting tightening device with rolled hardened
screw.
Interchangeable mobile clamping surface.
Reinforced model. Throat: 120mm. Bar cross section 27x13mm. Reachable pressure with
150mm opening: approx. 8500 N (850 kg).
Useful opening
mm
200
250
300
400
500
600
800
Weight
Kg 2,00
2,11
2,24
2,45
2,70
2,96
3,5
5245GP
Each 59,40 62,10 64,10 69,10 73,70 78,80 86,60
Useful opening
mm
1000
Weight
Kg
3,9
5245GP
Each 97,00
vuoto
UNIVERSALSTEELBARCLAMPS
5245GR
In forged and hardened steel, profiled bar.
Quick adjusting tightening device with rolled hardened screw provided with hexagon to be
operated aslo with torque wrenches.
Interchangeable mobile clamping surface.
Reinforced model. Bar cross section 30x15mm. Reachable pressure with 150mm opening:
approx. 12000 N (1200 kg) equivalent to 40Nm torque value.
Useful opening
mm
300
400
500
600
800
1000 1250
Depth
mm 140
120
140
120
140
120
120
Weight
Kg 3,00
3,20
3,70
3,90
4,60
5,10
6,00
5245GR
Each 77,70 83,40 92,10 96,30 111,00 121,00 139,00
Useful opening
mm
1500
Depth
mm 120
Weight
Kg 6,60
5245GR
Each 156,00
vuoto
UNIVERSALSTEELBARCLAMPS
5245GS
Product description as Art. 5245GR
Reinforced model. Throat: 175mm. Bar cross section 40x20mm. Reachable pressure with
150mm opening: approx. 22000 N (2200 kg) equivalent to 80Nm torque value.
Useful opening
mm
300
400
500
600
800
1000 1250
Weight
Kg 5,50
6,10
6,60
7,20
8,30
9,40 10,80
5245GS
Each 117,00 129,00 140,00 152,00 163,00 194,00 226,00
Useful opening
mm
1500
Weight
Kg 12,10
5245GS
Each 253,00
vuoto
UNIVERSALSTEELBARCLAMPS
